BULBS

Fluorescent Bulb Replacement
The AC632DBC workstation contains one fluorescent bulb, and the AC648DBC
workstation contains two fluorescent bulbs. They may be replaced as needed with a 15W
Cool White Bulb.
To replace the fluorescent light bulb in the AC632 model:
CAUTION
1. Turn off power at the power entry module. Disconnect linecord from the power entry
module. See figure 4. (Page 10)
2. Completely open the folding front sash by carefully resting it on the head assembly of
the workstation.
3. Using both hands, turn the bulb counter clockwise ¼ turn and remove from the
light socket. See figure 7.
4. Install new bulb by sliding into the light socket and turning clockwise ¼ turn until the
bulb locks into place.
5. Reconnect linecord to power entry module. Turn the power on at the power entry module.
See figure 4. (Page 10)
AC632DBC model
14

MAINTENANCE

Disconnect the linecord from the power entry
module prior to proceeding.
Figure 7, Fluorescent bulb replacement.
AC648DBC model
