AirClean systems AC600 Series Operator's Manual page 10

Swell Latch
AC632DBC model
8) Ensure that the door switch cable on the right hand side of the head assembly is
secure. See figure 4.
CAUTION
9) Make sure that any exterior linecord connections are secure and seated properly. These
connections are located on the back of the workstation. See figure 4.
10) Locate the power entry module on the back of the workstation. Insert the female end of the
linecord into the power entry module and the male end into an appropriate electrical outlet.
See figure 4.
AC632DBC model
Power Entry
Module
Linecord
10
Figure 3, Swell latch locations.
Only use approved accessories with the exterior
connectors.
Figure 4, Linecord Connections.
Swell Latch
AC648DBC model
Power Entry
Module
AC648DBC model
Linecord
