2) Please be sure to use the referenced diagram while cutting your
spindle. The motor could be dislodged if the spindle is not cut properly
and is too long, due to excessive pressure. Warranty will be voided if
this occurs.
3) If the door thickness is even bigger than the full length of the spindle,
please contact us or the local dealer for extra-long screws and spindles.

5. Installation

A. Installation of the outside unit.
B. Installation of the inside unit.
1. Select the right rubber gasket for the
outside unit according to the door
thickness, and put the rubber gasket to
the back of the outdoor unit.
2. Make sure the UP marks are on the two
sides of the spindle, instead of top side.
3. Make sure the deadbolt is retracted.
4. Insert spindle through the 21mm hole.
5. Insert the connector and wire through
the bigger upper hole (Dia: 17mm).
Insert the two upper fixing posts
6.
through the small upper holes on the
door and the bottom post through the
bottom hole.
1. Put the rubber gasket to the back of the
inside unit
2. Connect the 2 sets of wires and insert all
the wires into the wire hole on the door.
3. Make sure the arrow mark on the
spindle tube of the inside unit on the top
position.
4. Insert the spindle through the spindle
®
Easy2Access A/S EASY-908 Pin Code lock
