Summary of Contents for DOD IS220W
- Page 2 Copyright ©2016 DOD Tech All Rights Reserved...
-
Page 3: Table Of Contents
CONTENTS 1. Safety Precautions ······································································································· 2 2. Package Contents ········································································································ 3 3. Camera Controls ·········································································································· 4 4. Installing Your Camera ································································································ 6 5. Getting Started ············································································································ 7 6. Camera Modes ············································································································ 9 7. Camera Settings ········································································································ 12 8. Transferring Files ······································································································· 16... -
Page 4: Safety Precautions
Other power adapters may create a safety hazard or damage the unit. Do not use damaged power adapters or cords. If damaged, please disconnect the power adapter and contact DOD Tech Support for assistance. Do not pull, insert, or bend the power cable using excessive force. -
Page 5: Package Contents
Package Contents Host computer User manual Stand Car charger *Supplied accessories may vary by region. -
Page 6: Cameracontrols
CameraControls... - Page 7 CameraControls Menu/SOS Emergency File Lock [ Record/Shutter/OK [ When the unit is on Recording, press it for stop Turns ON the On-Screen Display (OSD) menu, Exits Recording. and saves menu setting. It is not activated when When it is at Camera Mode, press it for photo the unit is on recording.
-
Page 8: Installing Your Camera
Installing Your Camera NOTE: Assemble the unit on to the bracket and mount the bracket on to the windshield glass. Only use the car charger provided by manufacture, others might cause malfunc ons or danger. Please cau ously select the loca on where the unit will be mounted, do not mount the unit in places that may obstruct the driver's view or a ect the normal opera on of their bag. -
Page 9: Getting Started
1. Insert the Micro SD Memory Card. Please format the Micro SD card when using the unit for the first time. To save recorded videos stably, DOD Tech recommends formatting your SD card every two weeks. Note: Please purchase a micro SD card for use with this unit. - Page 10 Getting Started 3. First Time Settings. Upon powering up the camera for the first time or after upgrading the firmware on the device, you will need to go through the Settings below. Select Language Select the language of your choice by pressing [ ] / [ ].
-
Page 11: Camera Modes
Camera Modes 1. Video Recording Mode When the car engine is started, the unit will automatically start video recording (it is mandatory to insert a micro SDHC class 6 memory card) When it is not connected to the car charger, press [ ] button to turn on the unit, and press [ button to start video recording. -
Page 12: Photo Mode
Camera Modes 2. Photo Mode Press [ ] once to Camera Mode. Press [ ] to take a picture. / ] cannot be activated when the unit is on Recording Mode, please press [ ] to stop recording and return to Standby Mode. Image Resolution Digital Image Stabilizer (on) Camera Mode... - Page 13 Camera Modes 3. Playback Mode Select the preview/next photo/movie. Press [ ] twice to enter Playback Mode. Press [ ] / [ ] to select the photo or movie clip you want to playback. Starting movie playing back. Press [ ] to playback.
-
Page 14: Camera Settings
Camera Settings Each mode has a unique set of settings. See the description below. Two Camera Settings pages are accessible: Video Recording Settings System Settings The menu settings can be switched by pressing If you move the cursor before pressing , you must exit and try again. - Page 15 Camera Settings Video Recording: First Settings Page Accessed by pressing once. Parking mode (Default: off) When function is enabled, dashboard camera will automatically switch to parking mode if vehicle is stationary for over 10 minutes. 1. Automatically records a 15-second video when motion detected within view range of camera. 2.
- Page 16 Format Language Completely deletes all files including locked footage on Sets the language. the Memory Card and optimizes the card for recording. 64GB cards should use DOD's formatting program for proper functionality. See the support section online. Date/Time Frequency Sets Year/Date/Time format.
-
Page 17: Photo Settings
Camera Settings Photo Settings Accessed in “Photo Mode”. WDR (Wide Dynamic Range) Image Size Cannot be changed. Shows WDR processing is Adjusts the size of the image. Higher megapixels enabled. increases file size and details. Color Anti-Shaking Apply a color filter to the photo. Helps reduce the effects of shaking when taking a photo. -
Page 18: Transferring Files
Using a 2.5mm AV cable, plug the 2.5mm connector into the camera’s AV port. Plug the RCA end into a compa ble port on your television or monitor. Firmware Update See the support sec on on DOD-Tech’s website for any available rmware updates and instruc ons.
