SYSTEM SPECIFICATIONS

Lower cut-off frequency, –6 dB:
_____________________________________________
Upper cut-off frequency, –6 dB:
_____________________________________________
Accuracy of frequency response:
_____________________________________________
Maximum short term sine wave acoustic output on axis
in half space, averaged from 100 Hz to 3 kHz:
_____________________________________________
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by driver unit
protection circuit):
_____________________________________________
Maximum peak acoustic output per pair @ 1 m distance
with music material:
_____________________________________________
Self generated noise level in free field @ 1 m on axis:
_____________________________________________
Harmonic distortion at 85 dB SPL @ 1 m on axis:
Freq:
_____________________________________________
Drivers: Bass
Treble
_____________________________________________
Weight:
_____________________________________________
Dimensions: Height
(including Iso-Pod™ table stand)
Height
(without Iso-Pod™ table stand)
Width
Depth
< 47 Hz
> 25 kHz
54 Hz – 20 kHz (± 2.0 dB)
@ 1 m > 104 dB SPL
@ 1 m > 96 dB SPL
> 110 dB
< 5 dB (A-weighted)
50...100 Hz < 2 %
>100 Hz < 0.5 %
130 mm (5 in) cone
19 mm ( / in) metal dome
3
4
5.0 kg (11 lb)
299 mm (11 / in)
13
16
285 mm (11 / in)
1
4
189 mm (7 / in)
7
16
178 mm (7 in)
CROSSOVER SECTION
Connector: Input: XLR female, balanced 10 kOhm,
_____________________________________________
Input level for 100 dB SPL output at 1 m:
_____________________________________________
Input sensitivity control range relative to max output:
_____________________________________________
Crossover frequency, Bass/Treble:
_____________________________________________
Treble Tilt control operating range:
_____________________________________________
Bass Roll-Off control:
_____________________________________________
Bass Tilt control operating range in –2 dB steps:
_____________________________________________
Desktop control:
_____________________________________________
The 'CAL' position is with all tone controls set to 'off'
and the input sensitivity control to maximum (fully
clockwise).

AMPLIFIER SECTION

Bass amplifier output power:
Treble amplifier output power:
Long term output power is limited by driver unit
protection circuitry.
_____________________________________________
Amplifier system distortion at nominal output:
THD
_____________________________________________
Mains voltage:
Voltage operating range:
Power consumption:
Idle
Standby in ISS mode
Full output
pin 1 gnd, pin 2 +, pin 3 -
-6 dBu
-12 dB (Constantly variable)
3.0 kHz
0 to –2 dB @ 15 kHz
–4 dB step @ 55 Hz
0 to –6 dB @ 100 Hz
–4 dB @ 160 Hz
50 W
50 W
< 0.05 %
100-240 V AC 50-60 Hz
±10 %
3 W
<0.5 W
60 W
English 9
