Summary of Contents for Genelec 8320A

  • Page 1 8320A 8330A Operating Manual...

  • Page 2: General Description

    8320A and 8330A Operating Manual General Description Genelec 8320A and 8330A are two-way smart ac- 8320 146 mm 5 tive monitors designed for demanding professional 8330 190 mm 7 applications. Genelec Smart Active Monitor™ (SAM™) digi- tal signal processing (DSP) built inside each smart...
  • Page 3 GLM User ed to the next monitor or subwoofer using an XLR Kit and software. The 8320A and 8330A are com- output (DIGITAL OUT). The AES/EBU digital audio patible with GLM 2.0 and later.

  • Page 4: Minimum Clearances

    Mounting Options the time before entering standby. The playback re- sumes once an input signal is detected. There is a The Genelec 8320A and 8330A offer several mount- slight delay before playback resumes. ing options: The Iso-Pod™ (Isolation Positioner/De- coupler™) vibration insulating stand allows tilting of Mounting Considerations the monitor to correctly align the acoustic axis.

  • Page 5: Safety Considerations

    Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pur- The 8320A and 8330A have been designed in ac- suant to part 15 of the FCC Rules. These limits are de- signed to provide reasonable protection against harmful cordance with international safety standards.
  • Page 6 Figure 4: Horizontal and vertical directivity plots of the 8320A and 8330A. 6 English...
  • Page 7 SYSTEM SPECIFICATIONS 8320 8330 Frequency range –6 dB: 55 Hz – 23 kHz 45 Hz – 23 kHz Accuracy of frequency response: ±1.5 dB (66 Hz – 20 kHz) ±1.5 dB (58 Hz – 20 kHz) Maximum short term sine wave acoustic output on axis in half >...
  • Page 8 Email genelec.china@genelec.com Figure 5: Frequency response plots in horizontal plane of the 8320A and 8330A. The lower curve is the monitor’s power response. www.genelec.com Genelec Document D0116R001 Copyright Genelec Oy 8. 2014. All data subject to change without prior notice...
