QUICK REFERENCE GUIDE
RS90A1
ACTIVESMART™ FRIDGE
900MM FRENCH DOOR
SLIDE-IN
CUSTOM PANEL
The new family size Fisher & Paykel Slide-in
refrigerators offer a new level of fit and finish
to deliver seamless kitchen integration. Designed
for easy installation to fit flush into new or existing
cabinetry with minimal 4mm gaps.
Customer Support
T +65 6741 0777 W fisherpaykel.com
FEATURES
BENEFITS
Seamless Integration
The Slide-in series minimises gaps through heavy-duty
inline hinges and adjustable doors enabling minimal
4mm gaps to create consistent lines throughout your
kitchen. The series fits flush with cabinetry to minimise
disruption and deliver design freedom.
Sized to Suit
The spacious 900mm French Door fridges are designed
for family life, with double doors for easy access
to uninterrupted fridge space.
Fresher Food for Longer
Your fridge door is the most used door in your home.
Every time you open it the temperature changes around
your food. ActiveSmart™ Foodcare intelligently adjusts
airflow in the fridge to create a stable and even
temperature that helps your food stay fresher for longer.
Easy Cleaning
Removable, spill-safe cantilevered glass shelves are
designed to contain drips and spills that can be simply
wiped away, while leaving the interior walls completely
smooth and easy to clean. Storage bins just need a wipe
to keep spotless.
Flexible Living
These fridges adapt to suit your lifestyle by streamlining
food preparation and organisation with SmartTouch
controls, flexible shelving and storage options, and
slide-out bins and trays. Crisp LED lighting in all
compartments lights up all the shelves, bins and trays.
Efficient
These ActiveSmart™ fridges intelligently adapt to daily
use cooling and defrosting only when they need to
without compromising on food care.
fisherpaykel.com

SPECIFICATIONS

Finish
Panel Ready
(apply your own cabinetry façade)
Dimensions
H1793 x W890 x D606mm
(excluding doors and handles)
Total Gross Volume
Refrigerator
Freezer
Total
Energy Rating
Performance
ActiveSmart™ Foodcare
Frost free freezer
Adaptive defrost
Humidity Control System
Accessories
Custom door panel set
Apply your own (not sold)
Brushed aluminium handle set
Part No. 24626
(sold separately)
Warranty
Parts & labour
Sealed system parts
For full specifications visit fisherpaykel.com
Product shown: Left - installed into a 900 x 1800mm cavity; Right - Alternative
installation into a 900mm x 1900mm cavity. Custom panel (indicative only, handles
sold separately).
349L
176L
525L
l
l
l
l
2 years
3 years

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS90A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fisher & Paykel RS90A1

  • Page 1 QUICK REFERENCE GUIDE FEATURES BENEFITS SPECIFICATIONS RS90A1 Seamless Integration The Slide-in series minimises gaps through heavy-duty Finish Panel Ready inline hinges and adjustable doors enabling minimal (apply your own cabinetry façade) ACTIVESMART™ FRIDGE 4mm gaps to create consistent lines throughout your...
  • Page 2 900MM ACTIVESMART™ SLIDE-IN REFRIGERATOR CAVITY PREPARATION Model no: RS90A1 (Panel Ready) Cavity Dimensions a Overall height of cavity** 1800 B Overall width of cavity when adjoining cabinetry can share 4mm door gap when adjoining cabinetry cannot share 4mm door gap...
  • Page 3 DATA SHEET 900MM ACTIVESMART™ SLIDE-IN REFRIGERATOR Model no: 1002 RS90A1 (Panel Ready) Millimetres Product Dimensions a Overall height of fridge 1793 B Overall width of fridge c Depth of fridge front panels (excl. handles)* D Overall depth of fridge (excl. front door panels)
  • Page 4 900MM ACTIVESMART™ SLIDE-IN REFRIGERATOR ALTERNATIVE INSTALLATION Model no: RS90A1 (Panel Ready) Custom Panel Dimensions a Height of bottom drawer panel B Minimum height of toekick panel* C Minimum depth of toekick panel * The bottom drawer panel can be extended lower to cover the grille. However in this installation scenario the product needs to be raised a minimum of 50mm from the floor to allow for adequate air supply.
