Page 1: Table Of Contents
Air Purifier AP-C310 Instruction Manual Table of Contents Safety Precautions Operating Precautions Installing the Unit Parts and Functions Installing the Deodorizing/Dust Collecting/Anti-Bacterial Filter How to Operate Maintenance Troubleshooting Specifications... -
Page 3: Safety Precautions
Safety Precautions Make sure you observe these safety precautions. Important information is printed on the product and in this instruction manual in order to prevent damage to property or prevent harm to the user or other people. Make sure you fully understand the following content (display/graphic symbols) before reading this text. If you ignore these precautions, it may cause serious injury by fire or electric shock. - Page 4 Required Plug the power plug in all the way. In case of an abnormality or malfunction, immediately stop its operation and unplug the power plug. If it is not plugged in all the way, it may cause electric If you continue operations during a malfunction, it may lead shock or fire.
-
Page 5: Operating Precautions
Operating Precautions Do not block the air inlet or air outlet. Do not use the unit near a TV or radio. It may reduce the cleaning capability of the unit causing It may cause distortion of video images or noise. clean air not to circulate throughout the entire room. -
Page 6: Parts And Functions
Parts and Functions Control panel ☞ page 7 Odor and dust monitor (indicates the room air quality in blue, yellow and red) ☞ page 5 Indicator ☞ page 7 Illumination intensity sensor ☞ page 5 Photocatalytic lamp Top cover button (inside the unit) (ones on each side) ☞... - Page 7 Photocatalytic Lamp The blue activated carbon in the deodorizing/dust collecting/ anti-bacterial filter does not use the conventional ultraviolet ray reaction type, but instead uses a new type of photocatalytic technology that reacts with visible light. The lamp in the product uses a long life blue LED, and does not have any effects on eyes or the human body in the way ultraviolet rays do, but since the light is strong, when performing maintenance such as removing the filter to replace it, unplug the...
-
Page 8: Installing The Deodorizing/Dust Collecting/Anti-Bacterial Filter
Installing the Deodorizing/Dust Collecting/Anti-Bacterial Filter Open the top cover. Close the top cover. While keeping the cover stopper pressed on each side of the unit, open the top cover. Note If the top cover does not shut properly, make sure the filter is set correctly. -
Page 9: How To Operate
How to Operate Power indicator Air volume indicator Light indicator Mode indicator Timer indicator Rapid High Middle Auto- matic Power button Mode button Air volume Timer button Light button Filter replacement indicator button ☞ page 9 Starting the Unit Changing the Air Volume Plug the power plug into the wall outlet. -
Page 10: Maintenance
Maintenance Notes when Cleaning ◦ Before cleaning, make sure to remove the power cord from the wall outlet. ◦ When wiping the unit, always use a soft cloth or cotton swab. Using a stiff brush or something similar may scratch or damage the unit. ◦... -
Page 11: Dust Sensor
Dust Sensor Replacing the Deodorizing/Dust Collecting/Anti-Bacterial Filter If dust builds up, the sensor sensitivity will become unstable. Remove dust every two months or so. Clean the dust sensor The deodorizing/dust collecting/anti-bacterial filter cannot be washed with water. Replace it regularly. often when using in an environment with excessive dust. -
Page 12: Troubleshooting
Troubleshooting Situation Points to check and how to handle Reference pages There is no air volume. Is the power cord plugged into the wall outlet correctly? → Plug the power cord into the wall outlet. The air volume is too weak. Did you remove the deodorizing/dust collecting/anti-bacterial filter from the polythene bag when you installed it? →... - Page 13 Situation Points to check and How to handle Reference pages The air purifying effect was not Is the unit placed in a location with bad air circulation such as in an area achieved. completely surrounded by something? → Install the unit on a level surface. Make sure unit is located at least 30 cm away from walls, furniture, curtains, etc.
-
Page 14: Specifications
Specifications Model name AP-C310 Singapore model: 220-240V 50-60Hz India model: 240V 50Hz Power Hong Kong model: 220V 50Hz Applicable floor area (m Air volume/Operation Middle High Rapid (2 hours) mode Power consumption (W) Air volume (m Operational noise (dBA) Dimensions (mm) - Page 16 JA-00020-0101...
