Specifications for the 9522A
OPTICAL
Optical specifications are measured with the BERT test enabled.
Model Type
Fiber Size
Tx Output Power (dBm)
Tx Optical Wavelength (nm)
Rx Receiver Sensitivity (dBm)
Optical Budget (dB)
1
Estimated Distance (km)
1
Distance estimations based on losses of 3.0 dB/km @ 850nm or 1.0 dB/km @ 1310 nm on 62.5/125 fiber and 0.35 dB/km @ 1310 nm or 0.25 dB/km at 1550 nm on 09/125 fiber
and include a 3db safety factor.
ELECTRICAL
Primary and Secondary Data I/O Ports
Interfaces (Dipswitch Selectable)
Connectors
Performance
Baud Rate
BER
Retiming Accuracy
Electrical Anti-Streaming
Timeout Selections
Alarm Contacts
Rating
Type
Connector
Power Requirements
Current Voltage
Source
PHYSICAL
Dimensions
Weight
S
62.5/125
–19
850
–38
19
5.3
RS232, RS422 4-wire, RS485 2- or 4-wire
DB25S (25-pin) configured as DCE
150 Baud to 115.2 Kbps (Auto Baud, no settings required)
9
10
or better at the minimum optical receiver power level
0.01% of pulse width for repeated signals
1, 2, 4, 8, 16, 32, and 64 seconds
28 VDC @ 100 mA
Form C (Normally Open, Normally Closed, Common)
Three terminals on five-pin removable screw terminal connector
400 mA @ 6 VDC
Chassis backplane
6.2 H x 1.6 W x 8.6 D in.
157.5 H x 40.6 W x 218.4 mm
2.8 lb.
952 gm
37
L
62.5/125
–20
1310
–38
18
15
LD
09/125
–18
1310
–38
20
48
