Operation of the 9522A with the Network Management System
(NMS) Software
Operation of the cards with the NMS Network Management System software provides the following
information:
Parameter
Card Location (Slot)
Card Name
Serial Number
Revision Number
Chronometer
Reset Cycles
Firmware Revision
Master/Local Mode
Fault Tolerant Daisy Chain
Mode
Primary Data Port Alarm
Status
Secondary Data Port Alarm
Status
Data Tagging Status
Primary Data Port Echo
Cancel Status
BERT Test Status
BERT TEST Result Status
Primary Port Setup Control
TX1- BERT Test Enable
TX2- BERT Test Enable
Temperature
*NMS users should set the Status and Limits for each parameter as required for the specific application when
the NMS software is operated for the first time, or a new card is added into the system.
When the 9522A card is installed into an existing system already utilizing NMS system software, an upgrade of
the software will be necessary to add the 9522A card to the software database in the NMS software. Consult
the factory for guidance on how to download the latest version of the software from the TKH Security USA
FTP download site.
Type/Comment
Calculated by the NMS software
Text – Factory Programmed into NV
ram on card
Text – Factory Programmed into NV
ram on card
Text – Factory Programmed into NV
ram on card
Numeric – Calculated – stored in NV
ram on card
Numeric – Calculated – stored in NV
ram on card, Represents the cumulative
number of power cycles
Text – Factory Programmed into NV
ram on card
Status – Represents current Set Up of
Primary Data Port
Status – Represents current Mode of
Primary Data Port
Status – Represents current Alarm
Status of Primary Data Port
Status – Represents current Alarm
Status of Secondary Data Port
Status – Represents current Data
Tagging Feature Status
Status – Represents current Echo
Cancel Feature Status
Status – Represents current BERT TEST
status
Status – Represents current BERT TEST
results
Control – Provides NMS control over Set
Up status
Control – Provides NMS control for
BERT Test on TX1
Control – Provides NMS control for
BERT Test on TX2
Analog – Detected on card
Default
Value Range
Status
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Master / Local
Fault Tolerant/
Daisy Chain
True (In Alarm)
False (Normal)
True (In Alarm)
False (Normal)
Tagging Enabled/
Disabled
Echo Cancel
Enabled/ Disabled
BERT TEST
Enabled/ Disabled
BERT Signal
Detected/ Not
Detected
Master Local
Enabled/Disabled
Enabled/Disabled
Deg C
36
Default
Limits
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Info
*
Info
*
Info
*
Info
*
Info
*
Info
*
Minor
*
Minor
*
N/A
N/A
N/A
N/A
N/A
N/A
Info
*
