3/8" Ratchet Wrench
Model No.:RP17411
INSTRUCTION MANUAL
ting
Contain:
◎ Technical Data
◎ Important safety rules
◎ Operating Instructions
◎ Maintenance
◎ Parts List
IMPORTANT:
Upon receipt of the product,
read and follow all safety rules,
operating instructions before first use it.
And retain this manual for future reference.
2013
Advertisement
Table of Contents
Related Manuals for Aeropro RP17411
Summary of Contents for Aeropro RP17411
-
Page 1: Instruction Manual
3/8” Ratchet Wrench Model No.:RP17411 INSTRUCTION MANUAL IMPORTANT: ting Upon receipt of the product, read and follow all safety rules, operating instructions before first use it. And retain this manual for future reference. Contain: ◎ Technical Data ◎ Important safety rules ◎... -
Page 2: Technical Data
※ Technical Data Square drive……………………………………………………………………………………3/8”(10mm) Free speed……………………………………………………………………………..……………160rpm Max torque………………………………………………………………………………..50ft/lb(67.5N.m) Avg. air consumption…………………………………………………………………... 4cfm(114 l/min) Operating pressure…………………………………………………………………………...90psi(6.3bar) Air inlet size……………………………………………………………………………….…………..1/4” Air hose……………………………………………………………………………………………..3/8” ID Weight…………………………………………………………………………………………...…..1.2 kg A weighted sound pressure level L …………………………………….………….89.6dB(A) K =3 dB Sound power level L ………………………………………………….…………100.6dB(A) K =3 dB ISO 28927-2 &... -
Page 3: Operating Instruction
※ Operating Instruction Description Die cast aluminum body, Reversible, Rubber scuff guards on nose and back, Built –in –air regulator varies speed & power, front exhaust, designed for removing and installing nuts and bolts. Also ideal for tire changing and general assembling work and other workshop applications. -
Page 4: Workplace Hazards
D isconnect the assembly power tool for threaded fasteners from the energy supply before changing the inserted tool or accessory. D o not touch sockets or accessories during impacting, as this increases the risk of cuts, burns or vibration injuries. ... -
Page 5: Additional Safety Instructions For Pneumatic Power Tools
I f you experience numbness, tingling, pain or whitening of the skin in your fingers or hands, stop using the assembly power tool for threaded fasteners, tell your employer and consult a physician. O perate and maintain the assembly power tool for threaded fasteners as recommended in the instruction handbook, to prevent an unnecessary increase in vibration levels. -
Page 6: Maintenance
adjusted. Without proper lubrication the tool will not work properly and parts will wear prematurely. Use the proper lubricant in the air line lubricator. The lubricator should be of low air flow or changing air flow type, and should be kept filled to the correct level. Use only recommended lubricants, specially made for pneumatic applications. - Page 7 If any of the following symptoms appears during your operating, stop using the tool immediately, WARNING: or serious personal injury could result. Only a qualified persons or an authorized service center can perform repairs or replacement of tool. Disconnect tool from air supply before attempting repair or adjustment. When replacing O-rings or Cylinder, lubricate with air tool oil before assembly.
-
Page 8: Exploding View
Shuiquetou Village, Pengjie Town, Luqiao District, Taizhou City, Zhejiang 318057, P.R. China We declaring that the machinery product name: Air Ratchet Wrench model: RP17411 type: Pneumatic fulfils all the relevant provisions of Directives 2006/42/EC based on EC type-examination of... - Page 9 Name, address and identification number of the notified body: TÜV Rheinland LGA Products GmbH Tillystrasse 2, 90431 Nürnberg, Germany 0197 and tested in accordance with below standards EN ISO 11148-6:2010...
