- Page 1 Xerox WorkCentre 3215/3225 ® ® Service Manual Updated 10/24/16 DAW 702P02832 October 2016...
-
Page 2: Table Of Contents
PL 5.2 Lower Fuser......................5-15 Cassette PL 6.1 Paper Tray ......................5-16 Platen PL 7.1 Scanner Module....................5-17 Control Panel PL 8.1 Control Panel ....................... 5-18 Part Number Index ......................5-19 Parts List October 2016 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... - Page 3 Parts List October 2016 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual...
-
Page 4: Pl 1.1 Main
140N63727 WIFI PWB – Platen (PL 7.1) 050N00680 Document Pad 022N02799 ADF Module (PL 1.2) 003N01117 ADF Hinge – Connector Cover 005N01172 Surge Protector (South Africa Only) Parts Lists October 2016 PL 1.1 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 5: Pl 1.2 Adf
PL 1.2 ADF Item Part Description 022N02801 ADF Feed Roll Assembly 127N07864 ADF Drive Motor 022N02800 ADF Retard Pad Parts Lists October 2016 PL 1.2 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 6: Pl 2.1 Covers
Duplex Gate – Spring – Front Cover Latched Sensor – CRUM PWB – CRUM Contacts – Front Cover – Manual Cover – Front Harness Cover – CRUM Harness Parts Lists October 2016 PL 2.1 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 7: Middle Cover
– Speaker – FAX Ground – Paper Stacker – Bin Full Sensor – Spring 004N00286 Output Support – Antistatic Brush – Exit Cover – Middle Cover Assembly Parts Lists October 2016 PL 2.2 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 8: Pl 4.1 Frame
Main Exit Frame – Paper Path Frame – Exit Sensor Frame – LSU Bracket Frame – Left Main Frame – Right Main Frame 062N00292 – Duplex (PL 4.2) Parts Lists October 2016 PL 4.1 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 9: Pl 4.2 Duplex
Pulley – Exit Gear – Flat Rubber Belt – Feed Roller – Duplex Base Frame – Duplex Latch 022N02795 DUPLEX-set to A4 – 022N02796 DUPLEX-set to Letter Parts Lists October 2016 PL 4.2 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 10: Exit Frame
Decurler Roller – Exit Shaft – Rubber Exit Dup – Inner Exit Roller – Outer Exit Roller – Exit Roll Holder – Spring – Exit Frame Assembly Parts Lists October 2016 PL 4.3 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 11: Pl 4.4 Paper Path
Manual Left Adjust – Manual Right Adjust – Lower Paper Guide – Pinion Gear – Roller Cover – – Idle Roller – Spring – Sub-Holder Idle Parts Lists October 2016 PL 4.4 5-10 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 12: Pl 4.5 Base Pick Up
Paper Drive Roller – Bushing 130N01760 Paper Feed Roll Assembly – Feed Roll Holder – Idle Pick Up Gear – One Way Clutch – Retard Roller Parts Lists October 2016 PL 4.5 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual 5-11... -
Page 13: Left Main Frame
Fuser Locking Lever – Hub Clutch Gear – Feed Gear – Feed Gear 2 – Cam Coupler – Coupling Lever 007N01803 Main Drive Unit – Harness Cover Parts Lists October 2016 PL 4.6 5-12 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 14: Right Main Frame
– Rear Guide – Lower Guide – Foot – Right Frame – Cable Clamp – LVPS Cover – Developer Right Guide – Spring – Ground Clip Parts Lists October 2016 PL 4.7 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual 5-13... -
Page 15: Pl 5.1 Fuser
Bushing – Rear Guide – Exit Idle Roller – Spring – Actuator Holder – Exit Sensor Actuator 126N00430 Fuser Module 110V – 126N00431 Fuser Module 220V Parts Lists October 2016 PL 5.1 5-14 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 16: Pl 5.2 Lower Fuser
Gear – Roller – Spring – Bushing – Left Jam Lever Link – Antistatic Brush – Jam Lever – Paper Guide Holder – Lower Fuser Assembly Parts Lists October 2016 PL 5.2 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual 5-15... -
Page 17: Pl 6.1 Paper Tray
Right Paper Guide – Paper Tray Handle – Paper Tray Rear Guide – Paper Tray Frame – Paper Tray Handle – Paper Indicator 050N00682 Paper Tray Parts Lists October 2016 PL 6.1 5-16 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 18: Pl 7.1 Scanner Module
Contact Image Sensor (CIS) – Drive Belt – Scanner Drive Motor – Scanner PWB – Flat Cable – Sensor – CIS Holder – CIS Guide Shaft 090N00182 Scanner Module Parts Lists October 2016 PL 7.1 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual 5-17... -
Page 19: Pl 8.1 Control Panel
(Dup / NW / Wifi) – 140N63729 Control Panel Assembly -3225 DN (Dup / NW) (Europe only) – 140N63730 Control Panel Assembly -3215 NI (NW / Wifi) Parts Lists October 2016 PL 8.1 5-18 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... -
Page 20: Part Number Index
PL 4.1 140N63727 PL 1.1 050N00680 PL 1.1 140N63728 PL 8.1 050N00681 PL 4.4 140N63729 PL 8.1 050N00682 PL 6.1 140N63730 PL 8.1 050N00683 PL 6.1 Parts Lists October 2016 Part Number Index 5-19 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual... - Page 21 Parts Lists October 2016 5-20 Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual...
