- Page 1 Go to biosdiagnostics.com for a FREE Log Book! PRECISION SERIES Instruction Manual Model : BD215...
-
Page 3: Table Of Contents
Care of the Device About Blood Pressure Normal Blood Pressure Values Common Blood Pressure Questions and Answers Getting Started About the BD215 About the LCD Screen Inserting the Batteries Using the USB Power Adapter Using the Device Setting the Time and Date... -
Page 4: Introduction
1.1 Features The BD215 uses oscillometric technology to measure the arterial blood pressure and pulse rate. The cuff is wrapped around the arm and automatically inflated by the air pump. The sensor in the device senses weak fluctuation of the pressure in the cuff produced by extension and contraction of the artery of the arm in response to each heartbeat. -
Page 5: B Care Of The Device
• Try to record your blood pressure regularly at the same time of the day and under the same conditions. This will help your physician detect any extreme variations in your blood pressure and thus treat you accordingly. • Morning Hypertension ( > 135 / 85 mmHg): Recently, several studies have identified elevated cardiovascular risks (heart failure, stroke, angina) associated with “morning hypertension”. There is a typical rise in blood pressure during the physiological changes from sleep to arising for the day. (see section 3.9) •... -
Page 6: About Blood Pressure
• Do not store the unit in direct sunlight, high humidity, or in places with a lot of dust. • Clean the device with a soft dry cloth. Do not use gasoline, thinner or similar solvents. Carefully remove spots on the cuff with a damp cloth and soap. Do not wash the cuff. 1.3 About Blood Pressure Your blood pressure level is determined in the circulatory center of your brain. Your nervous system allows your body to adapt or alter blood pressure in response to different situations. -
Page 7: Common Blood Pressure Questions And Answers
Category Systolic Blood Pressure Diastolic Blood Pressure Optimal < 120 < 80 Normal < 130 < 85 High Normal 130 - 139 85 - 89 Hypertension • Stage 1: Mild 140 - 159 90 - 99 • Stage 2: Moderate 160 - 179 100 - 109 • Stage 3: Severe > 180 > 110... - Page 8 Your blood pressure also increases and decreases under the following circumstances Blood pressure is higher than normal: • when you are excited, nervous, or tense • while taking a bath • during and after exercise or strenuous physical activity • when it is cold • within one hour after meals • after drinking tea, coffee, or other caffeinated drinks • after smoking tobacco • when your bladder is full Blood pressure is lower than normal: • after consuming alcohol • after taking a bath Why is the doctor’s reading different from the reading taken at home? Your blood pressure can vary due to the environment (temperature, nervous condition). When measuring blood pressure at the doctor’s office, it is possible for blood pressure to increase due to anxiety and tension.
-
Page 9: Getting Started
2. Getting Started 2.1 About the BD215 a) This section describes the various components of the Blood Pressure Monitor. Cuff Connection Wide Range Cuff User Switch / Select Button Start / Stop Button Memory Button Cuff Connector USB / Adapter... -
Page 10: About The Lcd Screen
2.2 About the LCD Screen The LCD screen displays the systolic and diastolic blood pressure measurements along with your heart rate. It also displays previously recorded measurements and the date and time, when the appropriate button is pressed. Symbol Guide User AM averaging Irregular Heartbeat Icon... -
Page 11: Using The Usb Power Adapter
3. Using the Device This section describes how to get the maximum benefit from your BD215 blood pressure monitor. Follow the instructions carefully to get an accurate measurement of your blood pressure and pulse rate. 3.1 Setting the Time and Date When you insert the batteries or USB adapter for the first time the LCD screen will show all the display elements for 2 seconds. -
Page 12: Select The User
3.2 Select the User This blood pressure monitor is designed to store 90 measurements for each of two users. Before taking a measurement, be certain that the correct user has been selected. 1. Press the button to toggle between User 1 and User 2. 3.3 Obtaining Accurate Measurements START STOP... -
Page 13: C Fitting The Wide Range Cuff
3.3C Fitting the Wide Range Cuff a) Put the end of the cuff (with fastener) through the metal ring, making the cuff a cylinder. (Ignore this step if your cuff is already set up.) Proper assembly allows the Velcro to match up properly. ®... -
Page 14: Measuring Your Blood Pressure
g) Remain seated in a comfortable room temperature for at least 5 minutes, then start the measurement. h) For those who cannot put the cuff on the left arm, put it on the right arm as shown. i) Consecutive measurements will cause blood accumulation in the lower arm which will affect the measuring results. -
Page 15: Discontinuing A Measurement
2. The device will switch off after 1.5 minutes when no button is pressed. NOTE: When the measurement is taken between 4am and 12pm the “ ” icon will be displayed 3.5 Discontinuing a Measurement If it is necessary to interrupt a blood pressure measurement for any reason (e.g. the patient feels unwell) the button can be pressed at any time. -
Page 16: Am Averaging (Morning)
START STOP 2. Press the button again, the display will show the average value of the morning readings (see Section 3.9). START STOP START 3. Press the button again, the display will show the last measurement taken with the date STOP START STOP... -
Page 17: Care And Maintenance
Malfunction Remedy The display remains empty when the device is switched 1. Check batteries for correct polarity. on. The batteries are inserted. 2. If the display is unusual, re-insert the batteries or exchange them for new ones. The pressure does not rise even though the pump is Check the connection of the cuff tube and connect running. -
Page 18: Year Warranty
If at any time, you are not completely satisfied with the performance of this device, call our BP Hotline and speak with a customer service person, who will make arrangements to have the device tested and repaired or replaced to your full satisfaction. If you have questions regarding the operation of your monitor call the BIOS Diagnostics Blood Pressure ™... -
Page 19: Technical Specifications
7. Technical Specifications Operating temperature: 10 to 40°C / 50 to 104°F Storage temperature: -20 to 55°C / -4 to 131°F Weight: 425 g (including batteries) Dimensions: 102 x 140 x 40 mm Measuring procedure: Oscillometric during deflation Measurement range: Systolic 50 – 250 mmHg Diastolic 30 – 180 mmHg Pulse 40 – 199 beats per minute Resolution: 1 mmHg Static accuracy: pressure within ±...
