System Introduction

3

Special Features

3.1
Mobile Auto PC : The Auto PC is a complete navigation and tablet PC
with many interesting features.
It has a 7" wide TFT LCD touch screen :
It supports from 800 X 480 pixel resolution up to 1024 X 768 pixel
resolution.
Industry leading multi-media capabilities : Auto PC can play all leading
multi-media file formats including MPEG4, WMA/DivX, MP3/WMA/AAC.
GPS navigation : Uren includes the SIRF CPS with internal antenna with a
1GB memory for premium.
Convenient audio system connection : Auto PC has FMT
Network capability : Auto PC supports 10/100 Mbps Lan IEEE803.11b/g.
Design : Auto PC has a slim and elegant design.
Multi-tasking : You can listen to music or watch a movie or video while
using the GPS system.
8

Specifications

3.2
standard section
Item
Display
Graphic part
Resolution
3D Graphic Support
Size
Weight
CPU
General
Memory
Storage
Navigation
GPS Antenna
Functions
Navigation Type
DMB
DMB Function
Normal DMB Data Broadcasting
Land-based Wire Lan 10/100Mpbs Ethernet(extension port included/option)
Function
Wireless Lan
Supported
Multi-tasking
System Recovery
Speakers
Microphone
FM Transmitter
Remote Control
TV Output
Input/Output
Interface
Extension Port USB 2.0 monitor Port 10/100 Mbps Ethernet port
Battery
Power Supply Battery Life
Input: 100~240 volts, 50~60 Hz/Output 12V, 4A
Power Range
System Introduction
V1
7"WVGA TFT LCD touch screen type
800*480(Max 1024*768) pixel
O
192(W)*120.5(H)*25(Depth)mm
695g
V1A 1Gigah
256MB DDR2 533
1.8" 30 GB(HDD)
Mini SD card slot
Internal type SIRF-3
Microsoft Streets & Trips 2007
Normal DMB included
O
External USB type option
O
O
Mono
Internal
O
O
O
USB 2.0, mini SD slot, headphone jack,
TV-output port
Internal Lithium-ion battery 1800mA
1.5 Hours
9
