- Page 1 JENSEN User s Manual...
-
Page 2: Beware
Furthermore, installation in a car should be done while the AutoPC is in its cradle. Audiovox cannot be held liable for any damage incurred by dropping the device. We recommend you use only the authorized Audiovox adapter as your power supply. -
Page 3: Proper Maintenance
Please keep all liquids away from the AutoPC to prevent shock or damage. Do not try to repair the AutoPC under any circumstances. Call the nearest authorized dealer for service. Warrantee is void if the customer tries to service the AutoPC by himself. Customer Service 1.2.1 If the AutoPC in any way does not operate according to specification,... -
Page 4: Table Of Contents
Complete System List Main System Pouch Vehicle Cigar Remote Control Output Cable from Adapter System to TV. Vehicle Attachment User Manual 1. Beware 1.1 Installation Instructions 1.2 Operating Procedures 1.3 Safe Storage 1.4 Proper Maintenance 1.5 Storage Instructions 1.6 Careful Use while Traveling 2. -
Page 5: System Introduction
Industry leading multi-media capabilities : Auto PC can play all leading multi-media file formats including MPEG4, WMA/DivX, MP3/WMA/AAC. GPS navigation : Uren includes the SIRF CPS with internal antenna with a 1GB memory for premium. Convenient audio system connection : Auto PC has FMT Network capability : Auto PC supports 10/100 Mbps Lan IEEE803.11b/g. -
Page 6: Name And Function Of Each Part
Names and Functions of Each Part Names and Functions of Each Part Headphone port TV port USB 2.0 port External I/O port Mini SD card slot* Some model do not have these ports. System Introduction Front Face LCD Color Display : Touch screen technology makes the Auto PC a joy to use. - Page 7 Star Button : Press the button to turn on the Auto PC. Green Button : System is in use Red : Battery is charging Stylus Pen Hole : Touch screen pen is inserted here for easy access at any time. Ventilation Duct : To keep the Auto PC cool, ventilation is on top.
- Page 8 A regular AC adapter and a car cigar jack adapter. Innowell recommends use of original adapters and only replacements provided by Audiovox. Audiovox voids guarantee if another source is used. USB Ports : Two USB 2.0 ports have been provided for maximum flexibility.
-
Page 9: How To Use Auto Pc
Lan Port : The Auto PC can connect to either a network or the Internet. Lan card speed is 10/100 Mpbs. External Monitor Expanded Port : You can connect to an external monitor for better resolution. You can use LCD and external monitor at the same time. -
Page 10: Jensen Space
Stylus Pen Stylus Pen replaces the mouse function. Holding the pen down on the touch screen for three seconds is equivalent to the right click of a mouse. Please return the stylus pen in its slot to prevent loss. How to use the Auto PC JENSEN Space After booting, JENSEN Space is shown. - Page 11 Navigation User-friendly GPS system for easy driving. Explorer Press the icon to start internet explorer Video Player You can play movie files. How to use the Auto PC MP3 Player This MP3 Player can play MP3 and WMA audio files. Windows You can go to Windows Original screen to execute Windows application programs.
-
Page 12: How To Use Navigation System
Setting You can find out about FM Transmitter, date/time. LCD brightness, volume, user setting preference and version information. Power Off You can shut down the system by pressing this button. Traffic Information This button connects you to the Internet. It allows you to find out about the traffic condition in your community. -
Page 13: How To Use The Explorer
How to use the explorer Press the icon to start internet explorer Execution You can double-click the internet icon or click the left side internet icon then click the center icon to start internet explorer How to use Video Player How to operate Double-click the video player icon or click the left side icon then click the center icon to start the video player. - Page 14 File Manager Menu Description 1 2 1 3 1 4 1 5 You can search from Windows Original screen. You can go into my computer or driver from the Search Window. You can go into my documents and sub-files. You can add selected files to the play list. You can erase selected items.
- Page 15 Video Player Setting Screen Basic Setting 1. Screen Size : Set the screen size to big/full size. 2. Shut down after play : Set if the system will automatically shut down after playing. 3. Brightness Setting : Set the XVID codec video. 4.
- Page 16 Audio Player Main Screen 11 1 2 13 1 4 Title bar Play Stop To front To next song Volume Control Set repeat Set play mode Set Shuffle mode Enter Audio File Manager Move the selected file to front of list Move the selected file up one step Move the selected file down one step Move the selected file to last of list...
- Page 17 1. From the Jensen Space, please choose the “Setting” 2. From the “Setting” menu, choose “FM Transmitter” tap as shown below. Note: Please notice that no sound plays while in FMT mode from the unit. 3. Choose the designated frequency by arrow up & down buttons or clicking the numbers.
- Page 18 Set Date/Time Select each item and use the up/down arrows to set the time and date. Set LCD Brightness/Volume Set LCD brightness and Standby time to save battery. You can also set volume How to use the Auto PC User Setting Select programs to assign to user1/2 buttons.
- Page 19 S/W Version You can check S/W version. You can update Firmware through the Internet. Using Windows XP If you click on the icon as shown above, the desktop screen appears. You can use typical windows programs on the desktop and set the Auto PC touch screen sensitivity.
- Page 20 Calibrate Decide how many dots (5. 9. 25) you will use to control and press the Calibrate button to open the configuration window. Press the center of the target for 2 seconds to adjust. You will need to press the same number of dots you selected. If, in the first boot the touch point does not work correctly, exit to the window mode and configure calibrate in the Touchware program.
- Page 21 Option/Tool Paint Tool : Open the Windows WP’s Drawing board. Drawing Tool : Right Button/Hide : Process program that helps the action of the mouse’s right button. Pressing the touch screen will Pressing the touch screen will bring the same effect of click the bring the same effect of click the left button of the mouse.
-
Page 22: Using The Remote Control
User Set Program 4.12 You can open programs you linked in User settings by clicking on the User1,2 buttons 4.13 Power If you press the power button of the main screen, a pop-up asking if you would shut down the system will appear. If you select “yes,” the system will shut down. -
Page 23: System Setup
Stop button: Stop when using Audio/Video Player. Not used. Previous/Next button: Move to previous or next song when listening to songs. When viewing video, use it to move back or forward 10 seconds. Repeat button: Use to repeat select phrases. Change screen button: Change screens when using multiple programs. - Page 24 Setting Time and Date System Time: You can set the time. But if you change the time through Windows the time will change according to that. System Date: You can set the date. But if you change the date through Windows the time will change accordingly. Set Advanced Specifically configures various settings.
- Page 25 Set Chipset Change the settings of the system’s Chipset. Be careful: Improper settings may cause critical problems Using the Remote Control Save settings You may save load settings Save Changes and Exit Discard Changes and Exit Discard Changes Load Optimal Defaults: Set Bios settings to system optimal mode. Load Failsafe Defaults Set Bios settings to system failsafe mode.
