A S S E M B L Y I N S T R U C T I O N S
Multi-Press Station
Includes Assembly for:
AP-5MPS
Multi-Press W/Nylon Pulleys (Standard)
AP-5MPD
Multi-Press W/Aluminum Pulleys (Deluxe)
A m e r i c a ' s P r e m i u m E x e r c i s e E q u i p m e n t
Revision Date 06-28-05
AP-5MPS_AP-5MPD Rev0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-5MPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tuff stuff AP-5MPS

Summary of Contents for Tuff stuff AP-5MPS

  • Page 1 A S S E M B L Y I N S T R U C T I O N S Revision Date 06-28-05 Multi-Press Station Includes Assembly for: AP-5MPS Multi-Press W/Nylon Pulleys (Standard) AP-5MPD Multi-Press W/Aluminum Pulleys (Deluxe) A m e r i c a ’ s P r e m i u m E x e r c i s e E q u i p m e n t...

  • Page 2: Assembly List

    Assembly of the AP-5MPS_AP-5MPD Congratulations on your new purchase of the AP-5MPS_AP-5MPD 1. We advise you to consult your local Tuff Stuff retailer if you Multi-Press Station. We hope you are completely satisfi ed with this should have a question or problem regarding the proper product and wish you many years of enjoyment.
  • Page 3 Weight Stack Frame Weight Stack Frame Note: Some parts have been cut away for clarity. AP-5MPS_AP-5MPD Multi-Press Station...

  • Page 4: Main Frame Assembly

    Step 2 Main Frame Assembly Using a rubber mallet, insert three Plastic End Caps 2 X 3 (#60) onto the tube-ends of the Main Frame (#10). Attach the Main Frame (#10) to the Bottom Cross Brace (#6) using hardware shown. Attach the Swivel Pulley Bracket (#19) to the Main Frame (#10) using hardware shown.
  • Page 5 Note: Some parts have been cut away for clarity. AP-5MPS_AP-5MPD Multi-Press Station...

  • Page 6: Bench Assembly

    Step 3 Bench Assembly Insert the Slide Carriage (#16) onto the Bench Frame (#4), locking it into place with the Pull Pin 1/2 X 5 5/8 (#64). Attach the Bench Frame (#4) to the Main Frame (#10) using hardware shown. Attach one side of the Support Bar (#17) to the Main Frame (#10) using hardware shown.
  • Page 7 Note: Some parts have been cut away for clarity. AP-5MPS_AP-5MPD Multi-Press Station...
  • Page 8 Step 4 Press Bar Assembly Connect the Pivot Arm (#12) to the Main Frame (#10) with the Pivot Axle 1 X 5 5/8 (#13) and secure the axle into place using hardware shown. Attach the Swivel Double Pulley Rod (#18) to the Pivot Arm (#12) with the Rod End 1/2-20 X 1 1/2 (#66) and secure them into place using one Shoulder Bolt 1/2 X 1 1/4 (#72) and one Nylon Insert Lock Nut 3/8-16 (#58).
  • Page 9 Note: It is recommended to use another person in assisting with this assembly. Note: Some parts have been cut away for clarity. AP-5MPS_AP-5MPD Multi-Press Station...

  • Page 10: Cable Routing

    Step 5 Cable Routing A. Begin routing the Multi-Press Cable (#11) under the Pulley 3/8 X 4 1/2 (#23-Labeled ) then up passing between the Pulley 3/8 X 4 1/2 (#23-Labeled ) and the Cable Retainer Bracket. B. Next, route the Cable (#11) down passing between the Pulley 3/8 X 4 1/2 (#23-Labeled ) and the Cable Retainer Bracket, then route it up passing between the Pulley 3/8 X 4 1/2 (#23-Labeled ) and the Cable Retainer Bracket.

  • Page 11: Parts List

    HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 BNH0275 RUBBER O-RING 1/8 X 1 1/2 BNH0722 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2 BNH0303 AP-5MPS Parts List All parts same as AP-5MPD, except for the part listed below ITEM NO. DESCRIPTION PART NO.
  • Page 12 D O N O T D I S C A R D T H I S M A N U A L L I M I T E D W A R R A N T Y TuffStuff warrants to the original purchaser only that TuffStuff equipment will be free from defects in material and workmanship.
