- See Front Cover Hardware Measurement Diagram rior to the Assembly of the AP-2TO 1. We advise you to consult your local Tuff Stuff retailer if you should have a question or problem regarding the proper assembly of this Inner / Outer (AP-2TO).
Page 3
N O T E to position the Cam Support Tube (#5) and the Adjustable Cam (#4), as pictured above. Note: Be sure to position the Small Cover Plate (#15) shown in picture above. N O T E AP-2TO Inner / Outer (Option)
Page 4
Screws 3/8-16 X 1/2 (#45). Use the supplied Hex Key 3/16” (#58) to se- cure the two Set Screws 3/8-16 X 1/2 (#45) into the threaded sockets on Pivot Axle Support Tube (#6), as shown in caption above. AP-2TO Inner / Outer (Option)
Page 5
Leg Pad Pivot Brackets (#17). Diagram on page 7 for further clarification of this assembly. N O T E Note: Be careful not to distort the Retaining Snap Rings (#19) or bend them. N O T E AP-2TO Inner / Outer (Option)
Page 6
Note: Refer to Fig. B on page 9 for further illustration of this Cap Screws 3/8-16 X 4 (#44), four Flat Washers SAE 3/8 (#46) and two Cable Routing. Nylon Insert Lock Nuts 3/8-16 (#48). N O T E AP-2TO Inner / Outer (Option)
Page 7
AP-2TO Cable (#50) using the hardware illustrated in Fig. A on the back page. Fully Fasten: It is highly recommended that you double check and fully fasten all hardware assemblies and inspect the cable routing. AP-2TO Inner / Outer (Option)
Page 12
D O N O T D I S C A R D T H I S M A N U A L H O M E L I F E T I M E W A R R A N T Y TuffStuff products are warranted to the retail purchaser to be free from defects in materials and workmanship.
