Operator's Manual
FlexCut
Register your machine:
www.lincolnelectric.com/register
Authorized Service and Distributor Locator:
www.lincolnelectric.com/locator
Save for future reference
Date Purchased
Code: (ex: 10859)
Serial: (ex: U1060512345)
IM10197-B
| Issue D ate Oct-16
© Lincoln Global, Inc. All Rights Reserved.
™
80
For use with machines having Code Numbers:
12249, 12589
