N R
AVIGATION IN ADAR
You can mark waypoints and start navigation from the Radar View. See your control head operations manual for more information
about navigation.

Mark a Waypoint

Mark a Waypoint at the Vessel Position
1. Press the MARK key.
Mark a Waypoint at the Cursor Position
1. Use the Cursor Control key to move the cursor to a position on the view.
2. Press the MARK key.

Start Navigation

1. Press the GO TO key.
2. Select Nav Data. Press the RIGHT Cursor key.
3. Use the Cursor Control key to select a saved route or waypoint. Press the RIGHT Cursor key to start navigation.
4. Cancel Navigation: Press the MENU key once. Select Cancel Navigation, and press the RIGHT Cursor key.
V
IEW
19

Navigation in Radar View
