Adjust the Heading Line

Use the Adjust Heading Line setting to synchronize the on-screen heading with the actual boat heading so that north is displayed
correctly on the view.
1. Main Menu: Press the MENU key twice. Select the Accessories tab.
2. Select Radar. Press the RIGHT Cursor key to open the menu.
3. Select Adjust Heading Line.
4. Adjust Heading Angle: Press the RIGHT or LEFT Cursor keys, and a gray line will display on the view. Use the cursor keys to set
the angle of the heading line.
5. Save: Press the CHECK/INFO key.
Move the
gray heading
line to set
the heading
line angle.
Adjusting the Heading Line Angle
Press the RIGHT or
LEFT Cursor keys
13 Configure the Radar Settings
