Start Timed Transmission

Use Timed Transmission to set timed radar scans. This setting helps save power.
1. Main Menu: Press the MENU key twice. Select the Accessories tab.
2. Select Radar. Press the RIGHT Cursor key to open the menu.
3. Select Timed Transmit. Select On.
4. Use the Cursor Control key to select settings from the menus shown below.
Transmit Cycles
Standby Time
5. Close: Press the EXIT key repeatedly until the menu system is closed.

Stop Transmission

1. Open the Radar X-Press Menu: With a Radar View displayed on the screen, press the MENU key.
2. Select Radar.
3. Press the LEFT Cursor key. A dialog box will display on screen.
4. Press the LEFT Cursor key. Radar Transmission will stop, and the radar will enter Standy mode.
5. Power Off: Turn off the radar power source from the breaker or switch.
NOTE: The radar will continue to receive power until it is turned off at the power source (breaker or switch).
Start/Stop Radar Transmission
Sets the number of radar scans in Timed Transmission mode.
Sets the amount of time that the radar will pause between transmissions in Timed Transmission
mode.
10
Radar Settings Menu
