Edit an EBL/VRM Pair

An EBL/VRM must be saved to access this menu option.
1. With a Radar View displayed on-screen, press the MENU key.
2. Choose Edit EBL/VRM from the X-Press Menu, and press the RIGHT Cursor key. If there is more than one EBL/VRM, use the
Cursor Control key to select 1 or 2 from the submenu.
3. EBL: Press the RIGHT or LEFT Cursor keys to adjust the EBL.
4. VRM: Press the UP or DOWN Cursor keys to adjust the VRM.
NOTE: To adjust the VRM without the EBL, skip step 3. To adjust the EBL without the VRM, skip step 4.
5. Press the CHECK/INFO key to save your settings.

Delete an EBL/VRM

An EBL/VRM must be saved to access this menu option.
1. With a Radar View displayed on-screen, press the MENU key.
2. Choose Delete EBL/VRM from the X-Press Menu, and press the RIGHT Cursor key.
If there is more than one EBL/VRM, use the Cursor Control key to select 1 or 2 from the submenu and press the RIGHT Cursor
key.
15 Configure the Radar Settings
