STEP 4 - ALIGN DOOR

1.
Using a flat-blade screwdriver, gently insert the blade under the top hinge cover
and pry up to remove.
2.
Gently move wires aside.
3.
Using a Phillips-head screwdriver, loosen the three top hinge screws.
4.
Adjust the door and then tighten the screws.
5.
Replace the top hinge cover by first aligning the back of the cover with the back
of the hinge, and then pressing down firmly on the front of the hinge cover until
it snaps into place.
6.
Adjust bottom hinge, if necessary.

CONTROL PANEL AND FEATURES

CONTROL PANEL

LED Temperature Dispay
A
Temperature Increase Button
B

FEATURES

THERMOELECTRIC COOLING
Thermoelectric (also referred to as semiconductor) wine cellars offer high reliability
and low maintenance while precisely maintaining the set temperature for storing
wine.
Because thermoelectric wine cellars do not use a compressor for cooling there is
minimal noise and vibration. In addition to being extremely quiet, the lack of
vibration will keep bubbles from forming in stored wine.
Thermoelectric technology is environmentally friendly, because no CFC, HCFC, or
HCF-type refrigerants are involved in the cooling process.
Lower
a
b
C
D
7
c
d
Temperature Decrease Button
Interior Light Button
