EN
Operating Instructions
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAFFEO CI and is the answer not in the manual?

Questions and answers

Related Manuals for Melitta CAFFEO CI

Summary of Contents for Melitta CAFFEO CI

  • Page 1 Operating Instructions...

  • Page 4: Safety Instructions

    – Do not undertake any changes You must observe the safety to the appliance, its components instructions to avoid dangers. Melitta ® accepts no liability for damage caused or its accessories. by failure to observe the safety –...
  • Page 5 Warning! – hildren must not play with the appliance. Cleaning and Risk of burning and scalding maintenance must not be Escaping fluids and steam may undertaken by children younger be very hot. Parts of the appliance than 8 years of age. Children also become very hot.
  • Page 6 At a glance Figure B Figure A Power cable Brewing unit and identification Drip tray with cup plate and coffee label (behind the cover) grounds container (internal) Grinding fineness adjustment Float for the water level indicator in the drip tray Buttons Height-adjustable outlet with LED cup illumination...

  • Page 7: Before Using For The First Time

    • Filling the bean container (“Filling the When using for the first time, the bean container”, page 25). appliance may only be switched on Then fill the water reservoir: without a Melitta Claris water filter. ® ® • Raise the lid of the water reservoir 6 and...

  • Page 8: Preparing A Cappuccino

    Preparation Filling the bean container • Fill the water reservoir with fresh water Warning! every day. The water reservoir must always be filled with enough water for Hazard for persons allergic to caffeine. the operation of the appliance. Since a residual quantity of the •...

  • Page 9: Preparing Beverages With Ground Coffee

    Preparing milk froth or warm milk • Connect the tube with the outlet and (depending on the model) the supplied • Switch on the appliance. Melitta CAFFEO milk container ® ® ® • Place a vessel under outlet 3. (Image C) or insert in a conventional milk carton.

  • Page 10: My Coffee Button: Preparing Beverages With Personal Settings

    Overview of sub-menus • Press the button. Coffee dispensing starts. If no coffee was dispensed from submenu Meaning the appliance within 3 minutes after opening the ground coffee chute, the “Exit” To exit the main menu appliance will switch back to coffee bean To enter personal coffee “My Coffee”...
  • Page 11 Editing user profiles The following settings are possible: • Dispensed quantity: 30 ml to 220 ml • Call up the My Coffee sub-menu • Coffee strength: can be adjusted in four • Select the desired user profile. When levels using for the first time, Name 1 to Name 4 as well as Standard are available for (from = mild to...

  • Page 12: "Care" Sub-Menu

    "Care" sub-menu “Set clock” sub-menu Here, various integrated care and cleaning Here, the time can be changed or programmes can be started. disabled. • Call up the Set clock sub-menu. Menu Meaning • Select the current hours and minutes. option The appliance then returns to the main “Exit”...

  • Page 13: "Language" Sub-Menu

    “Water hardness” sub-menu Resetting the appliance to the default settings Here, the water hardness can be set. Use • Call up the System sub-menu. the test strip provided to determine the water hardness in your area. In doing so, • Select Factory settings in the menu. please comply with the instructions on the •...

  • Page 14: Adjusting The Grinding Fineness

    Adjusting the grinding Cleaning and maintenance fineness Warning! The grinding fineness level was optimally adjusted prior to delivery. It is therefore – Pull the power supply plug before recommended to only adjust the grinding cleaning. fineness after about 1  0 00 coffee –...

  • Page 15: Rinsing The Coffee Unit (Rinsing)

    Rinsing the coffee unit (Rinsing) Only use Melitta milk system cleaning ® agent. The appliance performs an automatic • Clean the milk tube and the milk outlet rinsing of the coffee unit when it is opening. switched on and off. The coffee unit can also be rinsed in between.

  • Page 16: Integrated Cleaning Programme

    200 brewed cups of coffee, at the latest, however, when a corresponding message appears on the text display 4. Only use Melitta cleaning tabs. ® • Flip up the lid of the water reservoir 6. • Pull the water reservoir 6 up and out of the appliance.

  • Page 17: Integrated Descaling Programme

    6 up and out of appears on the text display 4. the appliance. Only use Melitta ANTI CALC. ® • Rinse the water reservoir 6 thoroughly. • Call up the Care sub-menu.

  • Page 18: Inserting, Changing And Removing The Water Filter

    • Unscrew the water filter from the thread tap water for several minutes before on the base of the water filter. inserting it in the appliance. • Carefully screw the new Melitta Claris ® ® • Call up the Care sub-menu.

  • Page 19: Removing The Water Filter

    ® • Place a vessel under outlet 3. not remain dry over an extended period of time. It is therefore recommended to • Call up the System sub-menu. store the Melitta Claris water filter in the ® ® • Select Venting in the menu.

  • Page 20: Troubleshooting

    Troubleshooting Fault Cause Measure Adjust the grinding fineness more coarse. Coffee only flows drop-by- Grinding fineness is too fine. Clean the brewing unit. drop. Perform a descaling or cleaning programme if necessary. Water reservoir not filled or Fill the water reservoir and make incorrectly inserted.
  • Page 21 01 32 A Thorpe Wood Business Park September 2013 from a dealer authorized due to his expertise Thorpe Wood by Melitta, we give a manufacturer’s guarantee based on the Peterborough PE3 6SR following conditions: United Kingdom 1.
  • Page 22 Version 4.0 09/2016 1236-0816 Melitta Europa GmbH & Co. KG D-32372 Minden...
