SAFETY INSTRUCTIONS & DISCLAIMERS Caution: keep small parts away from children. Strangulation hazard: children can become entangled in cords. Power cords should be kept more than 3 feet away from the crib and baby’s reach at all times. Baby monitors and cameras with power cords should never be hung on or near the crib. This product is not a toy and should be kept out of children’s reach.
Page 3
SAFETY INSTRUCTIONS & DISCLAIMERS Damage requiring service: this unit should be serviced by qualified personnel only when: Objects have fallen or liquid has been spilled into the unit. The units have been exposed to liquids or moisture. The units do not appear to operate normally or exhibit a distinct change in performance. The units have been dropped or the enclosure damaged.
Page 4
FCC STATEMENT FCC CAUTION: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 5
IC STATEMENT IC WARNING This device complies with CNR Industry Canada license-exempt devices. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The device is compliance with RF exposure guidelines, users can obtain Canadian information on RF exposure and compliance.
We take quality very seriously. This is why all of our products come with a one-year warranty from the original purchase date against defects in workmanship and materials. If you have warranty or support issues please contact us using any of the following methods: Web: www.mylevana.com Support: www.mylevana.com/Support_Center.eng.html LEVANA Canada LEVANA USA 4080 Montrose Road 840 Aero Drive Niagara Falls, ON Cheektowaga, NY...
The warranty expressly provided for herein is the sole warranty provided in connection with the product itself and no other warranty, expressed or implied is provided. LEVANA assumes no responsibilities for any other claims not specifically mentioned in this warranty.
TABLE OF CONTENTS Safety Instructions & Disclaimers ......................................2 Support .................................................6 Warranty ............................................... 7 What’s Included ............................................10 Let’s Get Started ............................................11 Monitor and Camera Features ..........................................11 Battery Installation ..............................................12 Getting the Most Out of Your Rechargeable Battery ...................................12 Connecting Power to the Monitor / Charging the Battery ...............................13 Connecting Power to the Camera ........................................13 Placement of the Monitor ............................................14 Placement of the Camera .............................................14...
Page 9
TABLE OF CONTENTS Menu Functions ............................................19 Menu ..................................................20 Feed Timer ................................................21 Brightness ................................................. 23 Camera Views ................................................. 23 Camera Views ................................................. 24 Power Save Mode ..............................................25 Temperature ................................................28 Pairing..................................................30 Time Set ..................................................32 Support ..................................................33 Troubleshooting ............................................35 Specifications ............................................37...
LET’S GET STARTED MONITOR AND CAMERA FEATURES Power On/Off Button Power (Video Off) Button LED On Screen Indicator (LED lights show different levels Pairing Button Push To Talk of sound) (Press and hold to talk, release Power Indicator Light Antenna to listen) Light Sensor Back/Exit...
Insert the battery. The battery connectors NOTE: For extended periods of will line up with the non-use, Levana recommends connectors inside the removing the battery from the battery compartment. monitor. GETTING THE MOST OUT OF YOUR RECHARGEABLE BATTERY •...
LET’S GET STARTED CONNECTING POWER TO THE MONITOR / CHARGING THE BATTERY CONNECTING POWER TO THE CAMERA Warning: Baby monitors and cameras with power cords should never be hung on or near the crib as it is a strangulation hazard. Power cords should be kept no less than 3 feet away from the crib and the baby’s reach at all times.
LET’S GET STARTED PLACEMENT OF THE MONITOR PLACEMENT OF THE CAMERA You can place the monitor on a tabletop using the retractable table The camera can be placed on a tabletop or hung on the wall above stand on the back of the monitor. When not in use, simply tuck the the area being monitored.
LET’S GET STARTED MOUNTING THE CAMERA ON A WALL SAFELY Before drilling the holes, it is important to check the reception and camera positioning in the intended location on the wall. Ensure you are hanging the camera no less than 3 feet away from baby’s crib. Pre-drill two holes in the wall using a 3/16”, 4.8mm drill bit.
LET’S GET STARTED NIGHT VISION The camera is equipped with invisible IR (Infrared) LEDs which keep the nursery dark. The LEDs are located on the front of the camera and allow you to see up to 12 feet in complete darkness, so you can check on your baby at any time of night.
LET’S GET STARTED VOLUME Use the navigational arrows to increase / decrease / mute the volume. Press the button to increase the volume in live view; the Press the button to decrease the volume; to mute, decrease volume icon will display the volume level in the top left the volume until the icon appears in the top left corner of corner of the screen.
LET’S GET STARTED TALK TO BABY With the simple press of a button you can talk to your child at any time without entering the nursery. To talk, press and hold the button on the top right corner To talk when using multiple cameras, select the camera in the of the monitor and release to listen.
MENU FUNCTIONS MENU ICONS Sleep Mode Volume - 1 Temperature Paired Camera Volume - 4 Brightness - OFF Camera - 2 Volume - /Off / Mute Brightness - 1 Camera - 3 Talk to Baby Brightness - 2 Camera - 4 Timer - ON Brightness - 3 Signal - 1...
Battery - 50% MENU FUNCTIONS Battery - 75% Battery - 100% Signal - Full Signal - 3 Signal - 2 FEED TIMER Battery - 0-25% Signal - 1 Battery - 50% After feeding your baby you can set a timer that alerts you when it’s time for another feeding. Battery - 75% Volume - OFF Battery - 100%...
Page 22
Battery - 50% MENU FUNCTIONS Battery - 75% Battery - 0-25% Battery - 100% Battery - 50% Signal - Full Battery - 75% Signal - 3 Battery - 100% Signal - 2 FEED TIMER CONTINUED Signal - Full Signal - 1 Signal - 3 Use the LEFT and RIGHT arrows to navigate to the desired...
MENU FUNCTIONS BRIGHTNESS Brightness will allow you to control how dim or bright the picture on the monitor appears. Open the Menu and use the LEFT and RIGHT arrows Use the LEFT and RIGHT arrows to navigate to the desired navigate to the Brightness icon brightness you wish to set.
MENU FUNCTIONS Battery - 100% Signal - Full Signal - 3 Signal - 2 POWER SAVE MODE Battery - 0-25% Battery - 50% Signal - 1 Battery - 75% When enabled Power Save helps to extend battery life by shutting off the screen when no sound is heard or by making the monitor an audio Battery - 100% only monitor.
Page 26
Battery - 100% MENU FUNCTIONS LED Indicator - 1 Sleep Mode LED Indicator - 2 Signal - Full LED Indicator - 3 LED Indicator - 4 Talk to Baby Signal - 3 LED Indicator - 5 Signal - 2 POWER SAVE MODE CONTINUED LED Indicator - 1 Brightness - OFF Signal - 1...
Page 27
MENU FUNCTIONS Battery - 100% Signal - Full Signal - 3 Signal - 2 POWER SAVE MODE CONTINUED Signal - 1 Sensitivity Settings Volume - OFF Use the LEFT or RIGHT navigational arrows to toggle to the Sensitivity icon of your choice and press the Menu button once to select. Volume - 4 Return to continuous Live View, press the Back button to exit the Menu.
Battery - 50% MENU FUNCTIONS Battery - 75% Battery - 100% Signal - Full Battery - 0-25% Battery - 50% Signal - 3 Battery - 75% Battery - 100% Signal - 2 TEMPERATURE Battery - 0-25% Signal - Full Signal - 1 Battery - 50% Signal - 3 Battery - 75%...
Page 29
Battery - 50% MENU FUNCTIONS Brightness - 2 Battery - 75% Brightness - 3 Battery - 100% Signal - Full Brightness - 4 Signal - 3 Signal - 2 TEMPERATURE CONTINUED Signal - 1 Use the LEFT and RIGHT arrows to navigate to the desired Volume - OFF Press the orange Menu button to confirm the selection.
Battery - 75% MENU FUNCTIONS Battery - 0-25% Battery - 100% Battery - 50% Signal - Full Battery - 75% Signal - 3 Battery - 100% Signal - 2 TIME SET Signal - Full Signal - 3 Signal - 1 Time Set allows you to set the time that is shown on your monitor.
Battery - 0-25% MENU FUNCTION Battery - 50% Battery - 75% Battery - 0-25% Battery - 100% Battery - 50% Signal - Full Battery - 75% Signal - 3 Battery - 100% Signal - 2 SUPPORT Battery - 0-25% Signal - Full Battery - 0-25% 39 : Signal - 1...
Page 34
TROUBLESHOOTING TROUBLESHOOTING Reception interference (static) Monitor/Camera does not function The camera and monitor may be too far apart; try to move the unit Confirm that the camera and monitor are on. closer together. The battery may be depleted; try recharging the battery. The battery power may be too low;...
TROUBLESHOOTING Audio works but there is no picture The rechargeable battery will not charge The Power Save settings may be enabled. Press the power button The power adapters may not be connected. to turn the monitor screen back on. Press the orange Menu button The battery may not be properly connected inside the battery and tap Settings Power Save and tap the Audio Only icon to turn the compartment.
Page 36
SPECIFICATIONS MONITOR Maximum Monitors Expandable Up to 4 Cameras Battery Connection Charging Contact Supported Monitor Type TFT LCD Micro SD Recording Battery Life (Video + Audio On) 8 hrs Screen Size 5” Micro SD Capacity Battery Life (Sleep/Audio Only Mode) Up to 12 hrs Resolution 480 x 272...
