  • Page 1 IRD Quick Installation Guide V1.2-N   Integrated Digital Receiver Quick Installation Guide  ...
  • Page 2: Installation Instruction

    IRD Quick Installation Guide V1.2-N   1. Installation Instruction Mounting unit to a 19” rack When selecting the installation site, try to comply with the following: Protective Ground - The protective ground lead of the building's electrical installation should comply with national and local requirements. Environmental Condition - The installation site should be dry, clean, and ventilated.
  • Page 3: Wiring Connection

    IRD Quick Installation Guide V1.2-N   between each group to ensure good air ventilation. PIC-1.1-2 Wiring Connection Before setting up the connection, please turn off the equipment and all other connected external devices. The equipment and all connected external devices are required grounded.
  • Page 4: Power Connection

    IRD Quick Installation Guide V1.2-N   CVBS/SDI (area 3) Set up connection for network management control: shown in area 5. In order to ensure a smooth communication between the management PC and the equipment, please separate the connection of management port and TS/IP output port to different switch.
  • Page 5: Powering Up & Initializations

    IRD Quick Installation Guide V1.2-N   2. Operation Instructions Powering Up & Initializations Before powering-up the device, make sure that all cabling is correctly connected (refer to chapter 5.2). The device is correctly connected to the power inlet and grounded. Switch on the equipment through the back power switch, the unit is powered up and start the initialization.
  • Page 6: Check Out And Change The Default Ip Address

    IRD Quick Installation Guide V1.2-N   enter the configuration menu. Enter “Menu”: Press “MENU” button to enter main menu. Exit Menu/Back to parent Menu Upon completion of configuration settings, press “MENU” button until you go back to the Parent Menu. You can also go back to Parent Menu directly by pressing “ESC”...
  • Page 7: Configuration Through Web Management

    IRD Quick Installation Guide V1.2-N   2.2.3 Configuration through WEB Management Accessing the equipment through web can be very convenient for remote configuration of the equipment. Relative to the front panel settings, web operation can provide a more user-friendly man-machine interface, and less limits in space. For quick installation, web operation is highly recommended.
  • Page 8 IRD Quick Installation Guide V1.2-N   User can change the password after log on the device. Please refer to chapter XXXX of this document for the details. (Referring chapter 6.4.5 /Page 34) Possible reasons for unsuccessful log on: IP address/ network mask/gateway don’t match with the management PC’s User name/password is wrong.
  • Page 9: Quick Configuration On Key Parameters

    IRD Quick Installation Guide V1.2-N   (2) Parameter setting and configuration area: The parameters of the equipment are shown and configured here by selecting corresponding tabs. This is the main operation area of the WEB management. Quick Configuration on Key Parameters (Base Model) 2.3.1 Check “Status”...
  • Page 10 IRD Quick Installation Guide V1.2-N   Step one Step two PIC-2.3-2 2.3.2.1 Tuner IN To receive the signal from satellite via the device, connect the satellite siganl to the tuner port and operate as follows: -Step one: PIC-2.3-3 Choose the signal as input ,there are three options: ASI, Tuner1 and Tuner2, here we choose tunel as siganl source.
  • Page 11 IRD Quick Installation Guide V1.2-N   PIC-2.3-4 Configure the dual RF receiver parameters including the Satellite Frequency, Symbol Rate, LNB Frequency, and LNB Voltage (Polarization) with accurate values to ensure a successful receiving. You can get the value for the parameter from the satellite programs provider.  ...
  • Page 12: Configure Parameters Of Signal Output Modules

    IRD Quick Installation Guide V1.2-N   2.3.3 Configure parameters of signal output modules 2.3.3.1 Decoder OUT The device allows various signal outputs, including HDMI, SDI, CVBS and balanced audio. In this interface, user can view and configure the decoding output program information, including:Program, CAM, Video, Audio and Subtitle.
  • Page 13 IRD Quick Installation Guide V1.2-N   “program” section shows empty. The device decoding output is via its CVBS or HDMI output ports. For each time only one program can be set to decoding output. -Step two: scrambling configuration By changing the CAM operation, you can determine whether to descramble the program or not.
  • Page 14 IRD Quick Installation Guide V1.2-N   PIC-2.3-10 -Step six: Confirmation After completing configuration on the “program setup page” and press “Submit” button, connect a TV or monitor to the HDMI/CVBS port to check if the program has been decoded. 2.3.3.2 ASI OUT The ASI interface transmits the received signals (tuner or ASI) out for further process.
  • Page 15: Check "Status" Again

    IRD Quick Installation Guide V1.2-N   COMMON INTERFACE is used to interface between the pay-per-view card and the receiver. This is a defined standard that enables the addition of Conditional Access Module (CAM) in a DTV receiver to adapt it to different kinds of cryptography.
  • Page 16 IRD Quick Installation Guide V1.2-N   interface as following, where you can check the main information of the device. PIC-2.4-1 2.4.2 Configure parameters of signal input module 2.4.2.1 Tuner IN To choose signals from tuner as inputs, please operate as follows:  -Step one Before starting the receiving, check the connection to see if the satellite signal is high‐quality and ...
  • Page 17 IRD Quick Installation Guide V1.2-N   -Step two Get the accurate value of the satellite frequency, symbol rate and LNB frequency from satellite program provider and input them to the corresponding tab. After configuration, press submit button to take it into effect. PIC-2.4-3 ‐Step three ...
  • Page 18 IRD Quick Installation Guide V1.2-N   PIC-2.4-5 2.4.2.3 IP IN To choose IP stream as input source, click the sub-menu IP in “INPUTS” menu. Then it can turn to the IP parameter interface. -Step one Then, set the “Enable” item to be “ON” to access the IP channel, set the source IP address, Source Port and Protocol.
  • Page 19 IRD Quick Installation Guide V1.2-N   PIC-2.4-7 2.4.3 Configure parameters of signal output modules 2.4.3.1 Decoder Out Click the “Decoder Setup” menu and it will turn to the configuration page, where you can set the parameter of video and audio. Set the value to be compliant with the monitor or TV or just keep the default value.
  • Page 20 IRD Quick Installation Guide V1.2-N   PIC-2.4-9 Click the sub-menu “ASI” in Outputs menu and it will show the ASI configuration item in the right interface, where it is able to set the bit rate of ASI output as following: PIC-2.4-10 After that, click “submit”...
  • Page 21 IRD Quick Installation Guide V1.2-N   2.4.4 Program IN/OUT configuration in “Program Info” tab Parameters of input and output programs can be configured, just click the “programs” button on the left bar. Then it will turn to the programs information interface, in which parameters of the program can be modified and check.
  • Page 22 IRD Quick Installation Guide V1.2-N   click the TS. Then a prompt menu will appear as shown below, select “SCAN TS” it can be DVB or ATSC depending on the source. PIC-2.4-15 After completing the scan, all the input programs of that port will be scanned and displayed as follows: PIC-2.4-16 How to configure the output programs:...
  • Page 23 IRD Quick Installation Guide V1.2-N   PIC-2.4-17 Secondly, Input the “Original Network ID” and “TS ID” for the channel, and click the “OK” button. Then input “Original Network ID” and “TS ID” will be assigned to the selected output TS (channel). PIC-2.4-18 In addition, when editing icon was clicked, TS name, network ID and TS ID can be modified.
  • Page 24: Change The Password

    IRD Quick Installation Guide V1.2-N   After completing the configuration, click “Apply” button to enforce it or “Save” button to enforce and save it. 2.4.5 Change the password Choose “User management” menu and you will get the operation interface. Select the username and input the old password correctly, then you are able to change the password.
  • Page 25 IRD Quick Installation Guide V1.2-N   PIC-2.4-22 Quick installation is finished till this step. If you need more details or complete information of the device please refer to the user manual in attached user disc.  ...
