Praktica, Praktica FX & Praktiflex FX
Introduction
The PRAKTICA is a one-lens reflex camera taking the perforated 35 mm cine film. The size of the
picture is 24×36 mm.
The PRAKTICA possesses all the advantages of a modern precision miniature camera, e. g. shutter
winder coupled with film advancement, lock against double and blank exposures, interchangeability of
the lenses, and adaptability to microphotography.
Focusing is performed by means of a light-collecting lens which produces a clear, bright image.
The PRAKTICA takes all current daylight film cartridges for 36 exposures in black-and-white and
color film. The PRAKTICA FX is sure to give perfect results and mechanical safety if the instructions
for use are closely followed and carried out.

Explanation of signs

I. Inserting the film
The camera back is unlocked by pushing the knob No. 18 in the direction of the arrow. Open the
camera back and take it off, and pull out the rewind-knob No. 6.
The film cartridge must be placed into the empty chamber with the beginning of the film projecting
in the direction of the picture level. Pull the film from the cartridge and fix it into the empty spool on
the right-hand side of the camera.
It is of importance that the sprocket teeth catch both perforated edges of the film.
Wind the shutter by rotating the knob No. 2.
Make sure that the film lies evenly on the film guide and toothed drum, link the camera back into
the right-hand groove and close it down.
The film pressure-plate must be perfectly clean before the camera back is closed.
After having bolted the camera back, make two blank exposures. The rewind-knob (6) must hereby
turn in the opposite direction of the arrow mark.
When all these manipulations have been performed, the counting mechanism has to be set to stroke
No. 1.
The camera is now ready for the first exposure.
Praktica, Praktica FX & Praktiflex FX
(technically comparable cameras)
Instruction for use, 1952.
– 1 –
User manual, year 1952

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Praktica and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Praktica Praktica

  • Page 1 Instruction for use, 1952. Introduction The PRAKTICA is a one-lens reflex camera taking the perforated 35 mm cine film. The size of the picture is 24×36 mm. The PRAKTICA possesses all the advantages of a modern precision miniature camera, e. g. shutter winder coupled with film advancement, lock against double and blank exposures, interchangeability of the lenses, and adaptability to microphotography.
  • Page 2 Praktica, Praktica FX & Praktiflex FX User manual, year 1952 II. Changing the film 36 exposures having been made, a certain resistance will be noticed in winding the shutter – a sign that the whole film is exposed and has to be rewound into the cartridge.
  • Page 3 Praktica, Praktica FX & Praktiflex FX User manual, year 1952 When set to the speeds of 1/500th to 1/25th second, the red triangle on the supplementary knob No. 5 must point towards the black triangle on the camera top. When set to the speeds of 1/10th to 1/2 second, the red triangle on the supplementary knob must point to the red triangle on the camera top.
  • Page 4 Praktica, Praktica FX & Praktiflex FX User manual, year 1952 IV. Lens and Shutter a) Press the button No. 12, and the light-hood will spring up, uncovering the finder lens. When the shutter is wound up, a bright, clear picture will appear on the ground-glass surface of the finder. By turning the distance meter ring on the lens mount, the lens is focused to the greatest possible sharpness.
  • Page 5 V. Close-up Tubes (Macro-photography) The lenses in the Praktica make it possible for you to approach your object up to about 70 cm (28 in.). For expo- sures at shorter distances you will have to use intermediate tubes.
  • Page 6 User manual, year 1952 VI. The Prismatic Finder A Prismatic Finder is available as an accessory to the Praktica. At eye-level, this finder gives a ground glass view of the image – upright, correct-sided, and free from parallax error. The Prismatic Finder is attached to the top of the camera light-hood by fixing the nose marked “N”...
  • Page 7 Praktica, Praktica FX & Praktiflex FX User manual, year 1952 No. 11 (1/200) 1/10 No. 22 (1/500) 1/10 No. 31 1/10 1/10 No. 50 1/50 1/10 Sylvania Press 40 (1/200) 1/10 The guide 1/500 1/25 number is the No. 25...
