- Page 1 MARTIN PIT VIPER ™ ® Belt Cleaner Go to MARTIN ® PIT VIPER ™ Belt Cleaner web page Operator’s Manual M3735...
- Page 2 Important MARTIN ENGINEERING HEREBY DISCLAIMS ANY LIABILITY FOR: DAMAGE DUE TO CONTAMINATION OF THE MATERIAL; USER’S FAILURE TO INSPECT, MAINTAIN AND TAKE REASONABLE CARE OF THE EQUIPMENT; INJURIES OR DAMAGE RESULTING FROM USE OR APPLICATION OF THIS PRODUCT CONTRARY TO INSTRUCTIONS AND SPECIFICATIONS CONTAINED HEREIN.
-
Page 3: Table Of Contents
Part Numbers ............. 13 ® ™ Martin Engineering M3735-03/09 MARTIN PIT VIPER... -
Page 4: List Of Figures
PIT VIPER™ Belt Cleaner Assembly Part Numbers ....15 ® MARTIN PIT VIPER™ Belt Cleaner Blade Part Numbers ....16 ® ™ Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... -
Page 5: Introduction
® Belt cleaner If the belt cleaner is installed on enclosed pulley chutework, a MARTIN ® inspection access Inspection Door should be installed. MARTIN Inspection Doors are available from Martin Engineering or a representative. -
Page 6: Safety
WARNING Mainframe with blade can be heavy and may require two people to lift. Attempting to lift the belt cleaner without assistance could result in injury. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... -
Page 7: Before Installation
Keep any damaged goods subject to examination. 2. Remove belt cleaner assembly from shipping container. 3. If anything is missing contact Martin Engineering or a representative. DANGER Before installing, servicing, or adjusting the belt cleaner/... -
Page 8: Installation
Installation Locating and cutting mounting holes 2.75-3.00 (70-76) 7.50 (191) min. Operator Side ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... - Page 9 2 (cont.) Pulley Radius + Lagging Thickness + Belt Thickness + X 7.50 (191) Min. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner...
- Page 10 Head Pulley Face Repeat steps 2 and 3 on far side of chute. NOTE Refer to applicable tensioner manual for tensioner installation procedure. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner...
-
Page 11: Installing Mainframe And Blade
Installing mainframe and blade IMPORTANT If mainframe is too long to fit inside chute for installation, cut one or both ends of mainframe. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... - Page 12 Center cleaner blade on pulley. NOTE Refer to applicable tensioner manual to complete installation and adjustment of tensioner. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner...
-
Page 13: After Installation
• Material buildup. (No material between blades and return side of conveyor belt should be found.) 6. If wear, material buildup, or some other problem exists, see “Troubleshooting.” ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... -
Page 14: Weekly Maintenance
2. Make sure all fasteners are tight. Tighten if necessary. 3. Check tension on cleaner. Re-tension if necessary. 4. Wipe all labels clean. If labels are not readable, contact Martin Engineering or a representative for replacements. 5. Check blades for excessive wear. Replace if necessary. -
Page 15: Troubleshooting
It is not possible to predict all circumstances that may require troubleshooting. Contact Martin Engineering or a representative if you are experiencing problems other than those listed in the “Troubleshooting”... - Page 16 Notes...
-
Page 17: Part Numbers
Cable Tensioner Adapter Mount Plate Kit: P/N 38100. ® Operator’s MARTIN Single Spring Cable Belt Cleaner Tensioner Operator’s Manuals Manual: P/N M3734. ® MARTIN TWIST™ Belt Cleaner Tensioner Operator’s Manual: P/N M3296. ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner... - Page 18 Blade Width Mainframe Length 3.22 (82) 2.67 (68) 1.57 (40) 6.21 (158) 7.17 (182) 8.73 (222) 2.81 (71) ® Figure 1. MARTIN PIT VIPER™ Belt Cleaner Assembly, P/N PV1S-XXXXXXXXXX* ™ ® Martin Engineering M3735-03/09 MARTIN PIT VIPER Belt Cleaner...
-
Page 19: Pit Viper™ Belt Cleaner Assembly, P/N Pv1S-Xxxxxxxxxx
(0); standard painted mainframe (P). The last X indicates accessory options: no options (0); with spring cable tensioner ® ™ 54-inch belts or less only (C); with MARTIN TWIST tensioner (T); with spring cable tensioner with mount plate adapter 18-inch–54-inch belts only (M). -
Page 20: Conveyor Products Warning Label, P/N 23395
® Table II. MARTIN PIT VIPER™ Belt Cleaner Blade Part Numbers Assembly Part Number Blade Part Number Item 2 Color PV1S-XXXXXXBRXX PV-XXXXXXBR Brown PV1S-XXXXXXCLXX PV-XXXXXXCL PV1S-XXXXXXGRXX PV-XXXXXXGR Green PV1S-XXXXXXNBXX PV-XXXXXXNB Navy Blue PV1S-XXXXXXORXX PV-XXXXXXOR Orange ADVERTENCIA WARNING Lock out and/or tag out all energy sources to... - Page 21 Any product, process, or technology described here may be the subject of intellectual property rights reserved by Martin Engineering Company. Trademarks or service marks designated with the ® symbol are registered with the U.S. Patent and Trademark Office and may be proprietary in one or more countries or regions. Other trademarks and service marks belonging to Martin Engineering Company in the United States and/or other countries or regions may be designated with the “TM”...
- Page 22 We Make Your Bulk Materials Handling Cleaner, Safer and More Productive Through Personalized Performance. One Martin Place Neponset, IL 61345-9766 USA 800-544-2947 or 309-594-2384 Form No. M3735-03/09 FAX: 309-594-2432 © 2006, 2009 MARTIN ENGINEERING COMPANY. All rights reserved. www.martin-eng.com...
