178 003 75-2 2016-02-01
Providing sustainable energy solutions worldwide
Installation- and maintenance instruction
BG 450

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG 450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bentone BG 450

  • Page 1 178 003 75-2 2016-02-01 Providing sustainable energy solutions worldwide Installation- and maintenance instruction BG 450...
  • Page 3: Safety Directions

    DESCRIPTION Warning – Read the manual before assembling or commissioning. – The contents of this manual are to be observed by all who work for any reason on the unit and its appertaining system parts. – This manual is intended especially for authorised personnel. –...
  • Page 4 DESCRIPTION Components 1. Flame cone 11. Connection gas fittings 18. Switch l-ll (For modulating burner: 2. Inner assembly 12. Air intake Change-over switch manually- 3. Fixing flange 13. Air damper automatically) 4. Electric panel 14. Air pressure switch 19. Indicating lamp Stage 1 5.
  • Page 5: Technical Data

    TECHNICAL DATA Type designation BG 450 Dimensions Length of burner Flange tube Measure A Standard The above dimensions are max. measurements. Depending on the components used, the measurements may vary. Out range Type Capacity Gas volume at a min. Gas volume at a max Max.
  • Page 6 TECHNICAL DATA DIMENSIONS OF FLANGE 172 215 19 08-01...
  • Page 7: Skeleton Diagrams

    10. Gas burner control Required over 1200 kW accor - ding to EN 676. 5a. Gas pressure switch, mini 5b. Gas pressure switch, maxi 6a. Main valve. When Bio gas is used, Bentone shall always be contacted. 172 415 08 10-01...
  • Page 8 MOUNTING OF THE BURNER Fit the burner to the boiler by means When the burner head and the gas Ensure that the O-ring between the of 4 bolts M12. For flange and bolt flange have been fitted to the boiler it gas assembly and the gas flange will dimensions see technical data.
  • Page 9: Electric Equipment

    ELECTRIC EQUIPMENT Gas burner control: LGB21/LMG21/LME11/LME21 Wiring diagram If there is no Plug-in contact (X4,X6) on the boiler, connect to the contact Max loading K1 enclosed. Connection A1,A2 / 95, 96 / 97, 98 Max 0,2A/15W 1N ~ 50/60 Hz 230 V List of components Control thermostat Earth terminal...
  • Page 10 ELECTRIC EQUIPMENT Control diagnosis under fault conditions and lockout indication Gas burner control: LGB Lock-out and Control Programme Indication The position of the cam can be read through the sight-glass. Under fault condition the programme is stopped and thus also the lock-out indicator. The symbol visible on the cam indicates both the position in the programme run and the type of fault.
  • Page 11 ELECTRIC EQUIPMENT Control diagnosis under fault conditions and lockout indication Gas burner control: LMG ... Diagnosis of cause of fault After lockout, the red fault LED is steady on. For reading the cause of fault, refer to the blink code given in the following table: Press lockout reset button Red LED on LED on (waiting time≥10 s)
  • Page 12 ELECTRIC EQUIPMENT Control diagnosis under fault conditions and lockout indication Gas burner control: LME..Colour codes Colour code table for multi-coloured signal lamps (Light diodes) Status Colour codes Colours ○………………… Waiting time «tw», other waiting times Ignition phase, ignition checked •○...
  • Page 13: Interface Diagnostics

    ELECTRIC EQUIPMENT Control diagnosis under fault conditions and lockout indication Gas burner control: LME... Alarm control table Red flashing code Possible causes on signal lamp (LED) Flashing 2 x • No flame at End of «TSA» •• – Defective or obscured flame monitor –...
  • Page 14 MEASURES AND CHECKS BEFORE START-UP, 1-STAGE BURNER General rules Leakage control Care should be taken by the installer (0,5-2,5 sec. dependent on the design When making a leakage control of the to ensure that no electrical cables or of the gas control). The gas valve is gas supply system the solenoid valve fuel/gas pipes are trapped or damaged energized and opens and flame is...
  • Page 15 MEASURES AND CHECKS BEFORE START-UP Inner assembly Town gas Inner assembly Natural gas, LPG Natural gas Inner assembly Biogas ((UV-detector) 172 205 18 12-01...
  • Page 16 DETERMINATION OF GAS VOLUME FOR THE INSTALLATION Specifications on natural gas, town gas and biogas vary. For more exact information please contact the gas distributor. Net calorific value Gas quality kWh/Nm kJ/Nm kcal/Nm Natural gas 10.3 37 144 8 865 Propane 26.0 93 647...
  • Page 17 INSTÄLLNING AV MULTIBLOCK, MB-DLE 405-420 Mängdinställning Lossa låsskruven a. Vrid hydraulikdonet b: åt höger = mindre gasmängd åt vänster = större gasmängd Glöm inte att åter skruva fast låsskruven. Mängdinställning kan även ske med hjälp av tryckregulatorn. Det utgående trycket anpassas till ett värde som ger önskad gasmängd vid fullt öppen ventil.
  • Page 18: General Instructions

    GENERAL INSTRUCTIONS Adjustment of burner The burner is from the factory pre-set to an average value that must then be adjusted to the boiler in question. All burner adjustments must be made in accordance with boiler manu-facturers instructions.These must include the checking of flue gas temperatures, average water temperature and or O concentration.
  • Page 19: General Instruction

    GENERAL INSTRUCTION Flame monitoring and measurement of ionisation current The burner is monitored according to the ionisation principle. Check the ionisation current on start-up and on each service call. The reason for a low ionisation current may be leaking currents, bad connection to earth, dirt or a faulty position of the flame electrode in the burner head.
  • Page 20: Uv-Detector

    GENERAL INSTRUCTION UV-detector This should not be exposed to temperatures exceeding 60°C. The current passing through the UV-detector, when it is being illuminated, should be at least 70 µ A for LFL1.. This current can be measured by means of a moving coil instrument.
  • Page 21 GENERAL INSTRUCTION Adjustment of air pressure switch The air pressure switch should stop the burner, if the air volume is reduced. The air proving device shall be adjusted in such a way that if there is insufficien air supply at the highest or lowest burner operating stage, the device operates before the supervised pressure is less than 80% of the pressure at the controlled stage and the CO content of the combustion products exceeds 1% by volume.
  • Page 22 FINAL TEST OF THE INSTALLATION - Make repeated start attempts to ensure that the adjustments function. - Close the ball valve during operation to check that the gas switch switches off at the set value. - Remove the hose for the air pressure switch to check that the burner locks out.
  • Page 23: Gas Burner

    Fault location guide Gas burner The basis for a trouble free operation can only be ensured by the correct combined effect of the three factors: electricity, gas flow and combustion air. Should any of these factors change, troubles may arise. t has been proved that many troubles have rather simple causes.
  • Page 24 Cause Remedy No electrical connection through the air pressure switch Test the adjustment and the function of the air pres-sure switch. The starting load is not correctly adjusted Reduce or increase the gas supply, reduce the quanti ty of air. Gas relay defective Replace Air pressure switch incorrectly adjusted or defective...
  • Page 25 Cause Remedy The burner is operating correctly but locking out now and then The ionisation current is too low Check. Must be at least 4 µ A according to the relay manufacturer but should be 8-20 µ A. The UV-cell is in a wrong position Adjust Voltage drop at certain times Must not drop more than 15% of the rated...
  • Page 26: Declaration Of Conformity

    CE - märkningen. dessus, le brûleur recevra le marquage CE de conformité. Ljungby, Sweden, 141127 (27/11/14) Enertech AB Bentone Division is quality certified according to SS-EN ISO 9001 ENERTECH AB Bentone Division Enertech AB Bentone Division är kvalitetscertifierat enligt...
  • Page 28: Installation

    GENERAL INSTRUCTIONS FOR GASBURNERS Installation Follow standards and instructions applicable to the Check that the input pressure of the gas is correct installation of gas burners Check that the dampers of the boiler are open Ensure that the electric installation is made in Check that there is water in the system accordance with existing regulations Check that thermostats etc.
  • Page 29 SERVICE AND INSPECTION CARD Installation Boiler Name: Type: Efficiency kW: Address: Burner Type: Efficiency kW: Installed by: Date: Date gas/h Governor Flue gas Ionisa- Pressure Efficiency temp tion current Fire room Chimney Measure- Before After °C µ A mbar mbar % ment Small flame...
  • Page 32 Enertech AB. P.O Box 309, SE-341 26 Ljungby. www.bentone.se, www.bentone.com...
