REVERSING THE DOOR
To change the door opening direction on doors with NAUTIC-EUROPA closure:
Remove the bottom hinge and pull the door downwards.
Take off the Nautic handle (1) and fit it back onto the door, on the opposite
side, taking care to respect the distance between centres of the relevant holes.
Unscrew the hinge pin (2) from the bracket and screw it to the other side.
Refit the door, making sure that the closure operates effectively.
Refit the bottom hinge on the opposite side of the refrigerator.
To change the door operating direction on doors with NAUTIC-USA closure:
Remove the base of the fixing profile (1), if fitted.
Remove the hinge and bottom plate (2) and pull the door downwards.
Remove the Nautic handle (3), invert the stops and internal spring to change the
opening movement; turn the handle grip in the direction of the arrows.
Fit the Nautic handle back onto the door, on the opposite side, taking care to
respect the distance between centres of the relevant holes.
Move the catch plate (4) to the other side of the profile.
Refit the door, making sure that the closure operates effectively.
Refit the hinge, bottom plate and fixing profile base.
2
3
4
1
1
2
