TRAVELMATE-DZ
Nexberg Pty Ltd T/a Evakool
16 Enterprise St CALOUNDRA
QLD 4551
Tel :
07 5492 7777
Fax :
07 5492 7733
Please read these instructions and the Safety section carefully before using
1.Safety Instructions
2.Notes on using the product
3.Operation
4.WiFi Operation
5.Cleaning and Maintenance
6.Troubleshooting
7.Error Codes
8.Warranty Statement
1 | P a g e
Instruction Manual
your refrigerator.
NOTE:
Your fridge is preregistered with the
following user account for the APP.
User: 12345678900
Password: 123456
Page 2
Page 2
Page 2-4
Page 5-13
Page 14
Page 14
Page 15
Page 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRAVELMATE-DZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Danfoss TRAVELMATE-DZ

  • Page 1 TRAVELMATE-DZ Instruction Manual Nexberg Pty Ltd T/a Evakool 16 Enterprise St CALOUNDRA QLD 4551 NOTE: Tel : 07 5492 7777 Fax : 07 5492 7733 Your fridge is preregistered with the following user account for the APP. User: 12345678900 Password: 123456 Please read these instructions and the Safety section carefully before using your refrigerator.
  • Page 2: Operation

     Battery Protection: The Danfoss compressor requires approximately 11.0 Volts (12 Volt System) or 23.0 Volts (24V System) to operate. If the voltage drops below this the fridge will stop running.
  • Page 3 TRAVELMATE-DZ Instruction Manual 12/24V Volt Socket 240 Volt Socket SET Button Display LCD + / - Buttons ON / OFF Switch Emergency Switch USB Socket (0.5A) Using the Fridge Temperature setting range : - 18ºC ~ 1 0ºC, 0ºF ~...
  • Page 4 TRAVELMATE-DZ Instruction Manual To change the battery voltage setting press the SET button until the V is flashing and then • use the + or – buttons to change the setting. The three voltage settings are approximately as follows :- (We advise to keep the setting on V –...
  • Page 5 TRAVELMATE-DZ Instruction Manual WiFi OPERATION The fridge has been designed with the latest technology. You are able to easily download the EVAKOOL APP from the Google Play store or the Apple iTunes Store. Once the APP is installed please follow these easy instructions to be able to control and monitor your fridge.
  • Page 6 TRAVELMATE-DZ Instruction Manual PLEASE NOTE: You will not be able to use the internet while connected to the fridge. To pair the fridge with the APP, follow these steps:- Open APP If the fridge is not automatically added then you will need to click the ADD button at the bottom of the screen.
  • Page 7 TRAVELMATE-DZ Instruction Manual To register please fill out the fields:- USER ID – An 11 digit number i.e. 12345678900 Type – You need to select “Average User” the upgrade registration will be provided by Evakool. This can be obtained once your warranty is registered online by emailing sales@evakool.com...
  • Page 8 TRAVELMATE-DZ Instruction Manual You will then need to login using your registered details. USER ID : xxxxxxxxxxx (As per your registration) PASS : xxxxxx (As per your registration) NOTE – If you would like to upgrade the APP to be able to change the temperature and view the graph of voltage and temperature please follow the next steps.
  • Page 9 TRAVELMATE-DZ Instruction Manual Click Settings and then click Account Upgrade. Then Enter in your USER ID and the registration code provided to you by Evakool and then click SAVE. Your Account will now be upgraded. Once logged in you can view the fridge’s current running temperature and the voltage as well as any error messages.
  • Page 10 TRAVELMATE-DZ Instruction Manual When you click the settings button a menu will extend out from the right hand side where additional changes to the fridge can be made. Click the “Settings” Button. There are various menus in this side menu each of which is detailed below:- Settings –...
  • Page 11 TRAVELMATE-DZ Instruction Manual GRAPHING The fridge is able to log data of the temperature and voltage recorded by the fridge. This can be handy when trouble shooting. (E.g. If you have a problem once the fridge has been running for a while you can review this data.
  • Page 12 TRAVELMATE-DZ Instruction Manual The fridge can be switched on or off using the following screen. 12 | P a g e...
  • Page 13 TRAVELMATE-DZ Instruction Manual TROUBLESHOOTING THE WiFi APP I can’t see or connect the Wireless network Make sure WiFi is turned-on, on your device. • Make sure you are in range of the fridge (normally around 10-20 meters) • Make sure you are not connected to a different Wireless network •...
  • Page 14 TRAVELMATE-DZ Instruction Manual 5. Cleaning and maintenance • Clean the appliance inside and out with a damp cloth every week. If it is dirty, use sodium bicarbonate dissolved in lukewarm water to clean the unit. • Never use abrasive products, detergents or soap. After washing, rinse with clean water and dry carefully.
  • Page 15: Error Codes

    TRAVELMATE-DZ Instruction Manual Error Codes Code Reason / Solution ERR1 Thermistor is unplugged Contact Evakool ERR2 Thermistor is short circuited Contact Evakool Low Voltage Please check the source voltage to ensure it is above the cut out. Try lowering the voltage cut out setting to LOW.
  • Page 16: Terms And Conditions

    TRAVELMATE-DZ Instruction Manual EVAKOOL TRAVELMATE FRIDGE FREEZER RANGE Warranty Statement TERMS & CONDITIONS Nexberg Pty. Ltd. trading as EvaKool undertakes to the original purchaser that this product is sold free of defect in materials and/or workmanship under normal use for a period of 60 months. Subject to the following: - •...
