Nexberg Pty Ltd T/a Evakool
16 Enterprise St CALOUNDRA
QLD 4551
Tel :
07 5492 7777
Fax :
07 5492 7733
Please read this manual and the Safety Instructions carefully before using
1 |
P a g e
Instruction Manual
your refrigerator.
Page 2
Page 2
Page 2-4
Page 5-12
Page 13
Page 13
Page 14
Page 15
Advertisement
Related Manuals for Danfoss EvaKool SupaKool
Summary of Contents for Danfoss EvaKool SupaKool
-
Page 1: Table Of Contents
Instruction Manual Nexberg Pty Ltd T/a Evakool 16 Enterprise St CALOUNDRA QLD 4551 Tel : 07 5492 7777 Fax : 07 5492 7733 Please read this manual and the Safety Instructions carefully before using your refrigerator. 1. Safety Instructions Page 2 2. -
Page 2: Safety Instructions
Battery Protection: The Danfoss compressor requires over 10.8 Volts (12 Volt System) or 23.0 Volts (24V System) to operate. If the voltage drops below this the fridge will stop operating. - Page 3 Instruction Manual Cable Specification The DC cables must have a suitable cross-section for their length, according to this table: Cable Area 12V Max Cable 24V Max Cable Length* Length* [mm2] [ft.] [ft.] *Note: The length is from the battery to the refrigerator. Display Panel Using the Fridge TO TURN ON: Plug in the DC or AC power cable.
- Page 4 Instruction Manual SETTING THE TEMPERATURE: • Press SET once and then the display will flash then press the buttons to adjust the • temperature. Press the button to increase and the button to decrease the temperature. To lock in the target temperature press SET three times. The display board will display the current temperature inside the unit after the target temperature is set.
-
Page 5: Wifi Operation
Instruction Manual 4. WiFi OPERATION The fridge has been designed with the latest technology. You are able to easily download the EVAKOOL APP from the Google Play store or the Apple iTunes Store. Once the APP is installed please follow these easy instructions to be able to control and monitor your fridge. - Page 6 Instruction Manual Once you have connected to the Wireless network and it states that you are connected you can now proceed to pair your fridge with the APP. PLEASE NOTE: You will not be able to use the internet while connected to the fridge. To pair the fridge with the APP, follow these steps:- Open APP If the fridge is not automatically added then you will need to click the ADD button at the bottom...
- Page 7 Instruction Manual You will then need to register a new login. To register please fill out the fields:- USER ID – An 11 digit number i.e. 12345678900 Type – You need to select “Average User” the upgrade registration will be provided by Evakool. This can be obtained once your warranty is registered online by emailing sales@evakool.com requesting the upgrade code.
- Page 8 Instruction Manual You will then need to login using your registered details. USER ID : xxxxxxxxxxx (As per your registration) PASS : xxxxxx (As per your registration) NOTE – If you would like to upgrade the APP to be able to change the temperature and view the graph of voltage and temperature please follow the next steps.
- Page 9 Instruction Manual Click Settings and then click Account Upgrade. Then Enter in your USER ID and the registration code provided to you by Evakool and then click SAVE. Your Account will now be upgraded. Once logged in you can view the fridge’s current running temperature and the voltage as well as any error messages.
- Page 10 Instruction Manual There are various menus in this side menu each of which is detailed below:- Settings – Change the temperature, ºC or ºF and also the low voltage battery cut out. Graph – The fridge can log the temperature and voltage data. You can use this to make sure your fridge is operating correctly.
- Page 11 Instruction Manual GRAPHING The fridge is able to log data of the temperature and voltage recorded by the fridge. This can be handy when trouble shooting. (E.g. If you have a problem once the fridge has been running for a while you can review this data.
- Page 12 Instruction Manual The fridge can be switched on or off using the following screen. TROUBLESHOOTING THE WiFi APP I can’t see or connect the Wireless network Make sure WiFi is turned-on, on your device. • Make sure you are in range of the fridge (normally around 10-20 meters) •...
-
Page 13: Cleaning And Maintenance
Instruction Manual 5. Cleaning and maintenance • Clean the appliance inside and out with a damp cloth every week. If it is dirty, use sodium bicarbonate dissolved in lukewarm water to clean the unit. • Never use abrasive products, detergents or soap. After washing, rinse with clean water and dry carefully. -
Page 14: Error Codes
Instruction Manual Error Codes The error codes are depicted by a number of flashes by the error light in a sequence every four seconds. Code Reason Solution Please check the source voltage to ensure it is above the cut out. Try lowering the voltage cut out setting to LOW. -
Page 15: Warranty Statement
Instruction Manual EVAKOOL TRAVELMATE FRIDGE FREEZER RANGE Warranty Statement TERMS & CONDITIONS Nexberg Pty. Ltd. trading as EvaKool undertakes to the original purchaser that this product is sold free of defect in materials and/or workmanship under normal use for a period of 60 months. Subject to the following: - •... - Page 16 Instruction Manual 16 | P a g e...
