Custom Audio Electronics Vision15 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
VERSION 1.0 November 2011
Vision15
Vision15 Turbo
Hardware System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vision15 and is the answer not in the manual?

Questions and answers

Related Manuals for Custom Audio Electronics Vision15

Summary of Contents for Custom Audio Electronics Vision15

  • Page 1 USER MANUAL VERSION 1.0 November 2011 Vision15 Vision15 Turbo Hardware System...

  • Page 2: Important Safety Instructions

    Copyright 2011 All Rights Reserved Manual Version 1.0 Part Number: The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 4: Legislation And Weee Symbol

    LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release November 2011...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front & Side View ............3 2-2. Rear View with stand ..........3 2-3. I/O Ports View ............4 2-4. System Dimension ...........5 3.
  • Page 7 5. Specifications ......18 6. Jumper Setting ......20 6-1. C48 Motherboard ............20 6-1-1. Motherboard Layout ..........20 6-1-2. Connectors & Functions .......... 22 6-1-3. Jumper & BIOS/Utility Setting ......... 23 6-2. C68 Motherboard ............28 6-2-1. Motherboard Layout ..........28 6-2-2.
  • Page 8 The page is intentionally left blank. viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Accessories System (with stand) Driver CD Power adapter Power cord RJ45-DB9 cable (x3)

  • Page 10: Optional Accessories

    1-2. Optional Accessories MSR module VFD module (with RJ-45 cable) Second display (with VGA cable) Fingerprint module Wall mount kit Cable cover...

  • Page 11: System View

    System View 2-1. Front & Side View Item No. Description Touch screen MSR module (optional) Rugged footprint Ventilation HDD door 2-2. Rear View with stand Item No. Description VFD dummy cover MSR dummy cover...

  • Page 12: I/O Ports View

    2-3. I/O Ports View C48 Motherboard f g h i j k Item No. Description Power button 2nd VGA Parallel USB x 4 COM 1, 2, 3, 4 (from right to left) Line-out Mic-in Cash drawer Power switch DC-IN C68 Motherboard f g h i j k a b c Item No.

  • Page 13: System Dimension

    2-4. System Dimension 361mm 248mm...

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly 3-1. Stand Disassembly Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. Reverse the steps above to attach stand to the system. 3-2. Power Adapter Replacement Power adapter is secured to the system stand by a holding bracket and screws.

  • Page 15: Hd Replacement

    3-3. HD Replacement Please remove the current HDD first. To remove the HDD from the System Power the system down. Remove the screw(x1) from the HDD door. Open the HDD door. While pinching the HDD bracket tabs pull the HDD from the system.

  • Page 16: Open The System

    To install a new HDD. Attach the HDD to the bracket until it clicks in place. Make sure to press the edges of the drive not the center to avoid damaging the drive. Finally slide the HDD into the slot till it clicks.

  • Page 17: Ram Replacement

    3-5. RAM Replacement Follow the steps in Chapter 3-4 to open the system. The RAM is located on the right side of the system (see picture). Installing a RAM module Slide the memory module into the memory slot and press down until it locks in place.

  • Page 18: Peripheral Installation

    Peripheral Installation 4-1. MSR Installation MSR module can be installed to either side of the system. Choose one side and follow the steps below. Make sure the unit is powered down before starting. Remove the screws (x2) to release the MSR dummy cover. Connect MSR cable to the connector on system side.

  • Page 19: Fingerprint Installation

    4-2. Fingerprint Installation Fingerprint module will be installed to system prior to shipping once it is selected. To uninstall fingerprint module, please follow the steps below. Loose the thumb screw (x1) securing the module and slide the module outward as arrow shown. Loose the screw (x1) fastening the ground cable and disconnect the cable from the connector.
  • Page 20 Follow steps in Chapter 3-1 to disassemble the system stand. Attach the VFD module to system by fastening the screws (x2). Route the cable through cable mangement on the system stand. Connect the RJ-45 cable to COM 4 on the systems IO panel. Make sure the system is powered off.

  • Page 21: Second Display Installation

    4-3. Second Display Installation Follow steps in Chapter 3-1 to disassemble the system stand. Connect one end of the VGA cable to 2nd Display. Route the cable through cable mangement on the system stand. Attach the 2nd Display to system by fastening the screws (x2). Connect the other end of the VGA cable to 2nd VGA port on system IO panel.

  • Page 22: Wall Mounting Kit Installation

    4-4. Wall Mounting Kit Installation The Wall mounting Kit includes a wall plate, a metal bracket, and one screw. (refer to Chapter 1-2 item d) Please follow the steps below. Secure the wall plate to the wall by fastening screws (x4). 2.

  • Page 23: Cable Cover Installation

    4. Fasten the screw (x1) through the metal bracket to secure the wall mount kit. 4-5. Cable Cover Installation There are two different cable covers. These can be utilized separately or togeth- er. When both are needed, please take care that they are installed in the correct order.

  • Page 24: Cash Drawer Installation

    4-6. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 25 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 26: Specifications

    Specifications Model Name Vision 15 Vision 15 Turbo Motherboard Intel Sandy Bridge CPU i3-2120 3.3G, L2 3M, 65W CPU Support Intel Pinevew D525 1.8G L2 1M, dual core 13W Pentium G850 2.9G, L2 3M, 65W Celeron G530 2.4G, L2 2M, 65W Intel Q67 PCH (Processor Controller Hub, AMT supported_highend) Chipset...
  • Page 27 Mounting 100mm x100mm VESA mounting holes for Panel PC type Windows® XP Professional, Windows Windows® XP Professional, Windows Embedded POSReady 2009, Windows Embedded POSReady 2009, Windows XP OS Support XP Embedded, Windows XP Professional Embedded, Windows XP Professional for for Embedded, POSready 7, Vista, Embedded, WinCE, Vista, Windows 7, Linux Windows 7, Linux * This specification is subject to change without prior notice.

  • Page 28: Jumper Setting

    Jumper Setting 6-1. C48 Motherboard 6-1-1. Motherboard Layout PWR1 MINI_PCIE JP12 JP12 CN24 CN23 RJ45_2 JP10 JP10 JP19 JP19 CN22 RJ11_1 CN21 CN15 CN20 CN17 CN18 CN19 SKT1 JP14 CN16 JP14 CN14 CN13 CN27 CN31 SATA2 JP18 JP20 JP20 JP18 RJ45_1 CN11 CN26...
  • Page 29 DDR3_A2 C48 V2.1 BOTTOM LAYER...

  • Page 30: Connectors & Functions

    6-1-2. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN18 MIC IN CN20/JP10 System Indicator CN22 USB Port CN23...

  • Page 31: Jumper & Bios/Utility Setting

    6-1-3. Jumper & BIOS/Utility Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10...
  • Page 32 System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’.
  • Page 33 COM3 & COM4 Power Setting For C48, COM3/COM4 power adjustment must be made by BIOS/Utility and Jumper. Since COM3/COM4 default is “None“ meaning no power, power must be on through BIOS prior to physical jumper change. BIOS/Utility setup Press <DEL> key to enter BIOS SETUP UTILITY when system boot up.
  • Page 34 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. • Jumper Setup LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel 2nd: VGA port...
  • Page 35 4. To switch on the power, select "+12V". Please save the change before exiting BIOS to avoid data lost. • Intel Graphics Driver Setting Right click Desktop. Select the "Graphics Properties" and enter the menu. 2. Make sure the Display Device matches the image.

  • Page 36: C68 Motherboard

    6-2. C68 Motherboard 6-2-1. Motherboard Layout PWR1 CN18 PWR3 MINI_PCIE1 RJ45_1 CN19 RJ11_1 CN15 JP14 CN21 CN16 JP10 JP13 DDR3_A1 SATA2 RJ45_2 FAN_CPU1 CN10 CN11 SATA1 SKT1 JP11 JP12 USB1 CN14 USB2 CN12 CN13 CN17 PRN1 CN20 FAN_SYS1 JP15 Version: C68 v1.0...

  • Page 37: Connectors & Functions

    6-2-2. Connectors & Functions Connector Purpose CN1/2 SATA power Connector LVDS Connector LVDS INVERTER Connector SATA HDD LED Connector DVI Connector BATTERY Connector FT STATUS INTERFACE CN10/11 USB Port(Internal) CN12 Card Reader Connector(COM6) CN13 RF Connector CN14 COM5 for Touch CN15 SPEAKER &...

  • Page 38: Jumper Setting

    6-2-3. Jumper Setting Power Mode Setting Function ▲ATX Power AT Power COM2 RS232/485/422 Setting Function JP10 JP13 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10...
  • Page 39 Inverter Selection Function ▲ CCFL ME Update Function ▲Lock Un-lock Hardware Reset Function ▲System Normal System Reset USB Touch Power Setting for CN11 Connector Function JP11 ▲+5VSB ▲ = Manufacturer Default Setting...
  • Page 40 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 41 4. To switch on the power, select "Power". Please save the change before exiting BIOS so as to go for physical jumper adjustment. COM3/COM4 Jumper setup Function JP12 ▲+5V COM3 +12V COM4 ▲+12V...
  • Page 42 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 1366 x 768 Single...

  • Page 43: Appendix: Drivers Installation

    Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
