Philips Semiconductors
4
40 W BTL quad car radio power
amplifier
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
SYMBOL
V
supply voltage
P
V
short-circuit safe voltage
sc(safe)
V
reverse polarity voltage
rp
I
non-repetitive peak output current
OSM
I
repetitive peak output current
ORM
P
total power dissipation
tot
T
storage temperature
stg
T
ambient temperature
amb
T
virtual junction temperature
vj
THERMAL CHARACTERISTICS
SYMBOL
R
thermal resistance from junction to ambient in free air
th j-a
R
thermal resistance from junction to case (see Fig.6)
th j-c
2002 Mar 05
PARAMETER
PARAMETER
handbook, halfpage
OUT1
3.2 K/W
Fig.6 Equivalent thermal resistance network.
CONDITIONS
operating
non-operating
load dump protection;
during 50 ms; t
2.5 ms
r
virtual junction
OUT2
OUT3
OUT4
3.2 K/W
3.2 K/W
3.2 K/W
0.2 K/W
case
MGG157
7
Product specification
TDA8571J
MIN.
MAX.
18
30
45
18
6
10
7.5
60
55
+150
40
+85
150
VALUE
40
1
UNIT
V
V
V
V
V
A
A
W
C
C
C
UNIT
K/W
K/W
