Philips Semiconductors
4
40 W BTL quad car radio power
amplifier
FEATURES
Requires very few external components
High output power
Low output offset voltage
Fixed gain
Diagnostic facility (distortion, short-circuit and
temperature pre-warning)
Good ripple rejection
Mode select switch (operating, mute and standby)
Load dump protection
Short-circuit safe to ground and to V
load
Low power dissipation in any short-circuit condition
Thermally protected
Reverse polarity safe
Electrostatic discharge protection
No switch-on/switch-off plop
Flexible leads
Low thermal resistance
Pin compatible with the TDA8568Q, except for the gain.
QUICK REFERENCE DATA
SYMBOL
V
operating supply voltage
P
I
repetitive peak output current
ORM
I
total quiescent current
q(tot)
I
standby current
stb
I
switch-on current
sw
Z
input impedance
i
P
EIAJ output power
o(EIAJ)
SVRR
supply voltage ripple rejection
channel separation
cs
G
closed-loop voltage gain
v(cl)
V
noise output voltage
n(o)
V
DC output offset voltage
OS
V
delta DC output offset voltage
OS
ORDERING INFORMATION
TYPE
NUMBER
NAME
TDA8571J
DBS23P
2002 Mar 05
and across the
P
PARAMETER
plastic DIL-bent-SIL power package; 23 leads (straight lead length 3.2 mm)
GENERAL DESCRIPTION
The TDA8571J is a integrated class-B output amplifier
contained in a 23-lead Single-In-Line (SIL) plastic power
package. It contains four amplifiers in a BTL configuration,
each with a gain of 34 dB. The output power is 4
(EIAJ) into a 4
load.
APPLICATIONS
Primarily developed for car radio applications.
CONDITIONS
THD = maximum
R
= 0
s
R
= 10 k
s
R
= 0
s
MUTE
ON
MUTE
PACKAGE
DESCRIPTION
2
Product specification
TDA8571J
MIN.
TYP.
MAX.
6
14.4
18
7.5
200
0.2
100
80
25
30
40
50
50
33
34
35
170
80
80
VERSION
SOT411-1
40 W
UNIT
V
A
mA
A
A
k
W
dB
dB
dB
V
mV
mV
