DATA SHEET
TDA1563Q
2
25 W high efficiency car radio
power amplifier
Product specification
Supersedes data of 1998 Jul 14
File under Integrated Circuits, IC01
INTEGRATED CIRCUITS
2000 Feb 09

Advertisement

Table of Contents

   Related Manuals for Philips TDA1563Q

   Summary of Contents for Philips TDA1563Q

  • Page 1 DATA SHEET TDA1563Q 25 W high efficiency car radio power amplifier Product specification Supersedes data of 1998 Jul 14 File under Integrated Circuits, IC01 INTEGRATED CIRCUITS 2000 Feb 09...
  • Page 2 DBS17P 2000 Feb 09 GENERAL DESCRIPTION The TDA1563Q is a monolithic power amplifier in a 17-lead DIL-bent-SIL plastic power package. It contains two identical 25 W amplifiers. The dissipation is minimized by switching from SE to BTL mode when a higher output voltage swing is needed.
  • Page 3 Philips Semiconductors 25 W high efficiency car radio power amplifier BLOCK DIAGRAM V P1 handbook, full pagewidth TDA1563Q 2000 Feb 09 V P2 SLAVE CONTROL MUTE V ref 25 k MUTE SLAVE CONTROL STANDBY LOGIC DIAGNOSTIC MODE Fig.1 Block diagram.
  • Page 4 Philips Semiconductors 25 W high efficiency car radio power amplifier PINNING SYMBOL DESCRIPTION IN1+ non-inverting input 1 inverting input 1 common input electrolytic capacitor for SE mode supply voltage 1 MODE mute/standby/operating OUT1 inverting output 1 OUT1+ non-inverting output 1...
  • Page 5 With a sine wave input signal, the dissipation of a conventional BTL amplifier up to 2 W output power is more than twice the dissipation of the TDA1563Q (see Fig.10). In normal use, when the amplifier is driven with music-like signals, the high (BTL) output power is only needed for a small percentage of the time.
  • Page 6 --------------------- - 1.3 – – – – 2 6.5 2 6.5 Compared to a conventional BTL amplifier, the TDA1563Q has a higher efficiency. The thermal resistance of the 145 65 – heatsink should be: --------------------- - 2 6.5 2000 Feb 09...
  • Page 7 Philips Semiconductors 25 W high efficiency car radio power amplifier DC CHARACTERISTICS = 14.4 V; T = 25 C; measured in Fig.7; unless otherwise specified. SYMBOL PARAMETER Supplies supply voltage total quiescent current q(tot) standby current average electrolytic capacitor voltage at pin 4 DC output offset voltage Mode select switch (see Fig.4)
  • Page 8 Philips Semiconductors 25 W high efficiency car radio power amplifier V mode handbook, halfpage Operating Mute Standby Fig.4 Switching levels of the mode select switch. 2000 Feb 09 MGR176 Product specification TDA1563Q...
  • Page 9 Philips Semiconductors 25 W high efficiency car radio power amplifier AC CHARACTERISTICS = 14.4 V; R = 4 ; CSE = 1000 F; f = 1 kHz; T SYMBOL PARAMETER output power total harmonic distortion dissipated power power bandwidth low frequency roll-off...
  • Page 10 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, halfpage CLIP Fig.5 Clip detection waveforms. Fig.5 Clip detection waveforms. 2000 Feb 09 handbook, halfpage MGR177 DIAG maximum current Fig.6 Protection waveforms. Product specification TDA1563Q 10 s short circuit...
  • Page 11 Philips Semiconductors 25 W high efficiency car radio power amplifier TEST AND APPLICATION INFORMATION handbook, full pagewidth 0.5R s 220 nF 0.5R s 220 nF 0.5R s 220 nF 0.5R s 220 nF Connect Boucherot filter to pin 8 or pin 10 with the shortest possible connection.
  • Page 12 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth Dimensions in mm. Fig.8 PCB layout (component side) for the application of Fig.7. 2000 Feb 09 76.20 RL-98 Out2 2.5% Mode Mute Product specification TDA1563Q 35.56 Out2...
  • Page 13 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth Dimensions in mm. Fig.9 PCB layout (soldering side) for the application of Fig.7. 2000 Feb 09 76.20 2 25 W high efficiency Out2 220 nF 220 nF Product specification...
  • Page 14 25 W high efficiency car radio power amplifier handbook, halfpage Input signal 1 kHz, sinusoidal; V = 14.4 V. (1) For a conventional BTL amplifier. (2) For TDA1563Q. Fig.10 Dissipation; sine wave driven. input 2000 Feb 09 MBH692 handbook, halfpage P o (W) (1) For a conventional BTL amplifier.
  • Page 15 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth IEC-268 FILTER pink noise Fig.13 Test and application diagram for dissipation measurements with a music-like signal (pink noise). 2000 Feb 09 V P1 TDA1563Q 220 nF 220 nF...
  • Page 16 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, halfpage (mA) = 5 V; R Fig.14 Quiescent current as a function of V handbook, halfpage (1) EIAJ, 100 Hz. (2) THD = 10 %. (3) THD = 0.5 %.
  • Page 17 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, halfpage THD + N (1) P = 10 W. (2) P = 1 W. Fig.18 THD + noise as a function of frequency. handbook, halfpage (dB) (1) P = 10 W.
  • Page 18 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, halfpage = 70 mV. Fig.22 AC operating as a function of V 2000 Feb 09 MDA846 V p (V) Product specification TDA1563Q...
  • Page 19 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth V load V master 1/2 V P V slave 1/2 V P See Fig.7: or V load or V master or V slave 2000 Feb 09 t (ms) Fig.23 Output waveforms.
  • Page 20 A complete kit (application report, software and demo board) of this “car-audio chip-set demonstrator” is available. The TDA1563Q is a state of the art device, which is different to conventional amplifiers in power dissipation because it switches between SE mode and conventional BTL mode, depending on the required output voltage swing.
  • Page 21 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth TDA3617J Line-in Left Right PHILIPS Semiconductors 2000 Feb 09 Car-audio chip-set demonstrator TDA1563Q Rear 2.5% V BATT Car DSP SAA7704/05/08 on bottom side Power ON Mute Top copper layer Car-audio chip-set demonstrator Version 0.1...
  • Page 22 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth MICROCONTROLLER V BATT power 4.7 k power 4.7 k error mute 4.7 k diagnostic 4.7 k clip 3.3 V ANA VDACP 100 F VDACN1 PLANE 330 pF 8.2 k...
  • Page 23 Philips Semiconductors 25 W high efficiency car radio power amplifier handbook, full pagewidth Fig.26 Car-audio chip-set demonstrator (continued from Fig.25). 2000 Feb 09 V BATT GND PGND clip select 2.5% 2200 F V BATT (16 V) 220 nF V P1...
  • Page 24 The maximum dissipation with music-like input signals decreases by 40%. It is clear that the use of the TDA1563Q saves a significant amount of energy. The maximum supply current decreases by approximately 32%, which reduces the dissipation in the amplifier as well in the whole supply chain.
  • Page 25 Philips Semiconductors 25 W high efficiency car radio power amplifier INTERNAL PIN CONFIGURATIONS NAME 1, 2, 16, IN1+, IN1 , IN2 , 17 and 3 IN2+ and CIN MODE 7, 11 OUT1 , OUT2+ 2000 Feb 09 EQUIVALENT CIRCUIT V P1, V P2...
  • Page 26 Philips Semiconductors 25 W high efficiency car radio power amplifier NAME 8, 10 OUT1+, OUT2 14, 15 PROT, CLIP 2000 Feb 09 EQUIVALENT CIRCUIT V P1, V P2 8, 10 MGR186 V P2 MGR187 V P2 14, 15 MGR188 Product specification...
  • Page 27 Philips Semiconductors 25 W high efficiency car radio power amplifier PACKAGE OUTLINE DBS17P: plastic DIL-bent-SIL power package; 17 leads (lead length 12 mm) DIMENSIONS (mm are the original dimensions) UNIT 17.0 0.75 0.48 24.0 15.5 0.60 0.38 23.6 Note 1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.
  • Page 28 Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale.
  • Page 29 Philips Semiconductors 25 W high efficiency car radio power amplifier 2000 Feb 09 NOTES Product specification TDA1563Q...
  • Page 30 Philips Semiconductors 25 W high efficiency car radio power amplifier 2000 Feb 09 NOTES Product specification TDA1563Q...
  • Page 31 Philips Semiconductors 25 W high efficiency car radio power amplifier 2000 Feb 09 NOTES Product specification TDA1563Q...
  • Page 32 Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH, Tel. +41 1 488 2741 Fax. +41 1 488 3263 Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1, TAIPEI, Taiwan Tel. +886 2 2134 2886, Fax. +886 2 2134 2874 Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd., 209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260, Tel.
