Read: max 20x, cdrw max 14x; write: 1x, 2x, 4x speed

Manual - 215 pages
Service and reference manual - 138 pages
User manual - 97 pages

Locate the release latch. Slide the release latch to the unlocked position.

Remove the device from the NEC VersaBay III.

Installing the NEC VersaBay III CD-RW Drive

Follow these steps to install the NEC VersaBay III CD-RW drive in the NEC VersaBay III.

Save your files.

Shut down Windows and power off the NEC Versa.

Close the LCD panel and locate the VersaBay III on your system. For NEC VersaBay III

locations, see the previous section, "Removing a Device from the NEC VersaBay III."

If there is an NEC VersaBay III device in the NEC VersaBay III, refer to the instructions in

the previous section, "Removing a Device from the NEC VersaBay III."

Turn the NEC Versa upside down and locate the release lock and the release latch (see the

previous figure).

Slide the release lock to the unlocked position. Slide and hold the release latch in the

unlocked position.

Align and install the device into the NEC VersaBay III.

NEC VersaBay III release lock and latch

A - Release Lock

B - Release Latch

Installing the device into the NEC VersaBay III

NEC VersaBay III CD-RW Drive Pak 3
