PATIO HEATER
Owner's Manual
Standard:
ANS Z83.26-2007 / CSA 2.37-2007 & ANS Z83.26a-2008 / CSA2.37a-2008
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-537-8484, 8 a.m. - 8 p.m., EST or Saturday 9:30 a.m - 6:00 p.m.
E-mail: ps@frontgate.com.
Gas-Fired Outdoor Infrared Patio Heaters
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING
For Outdoor Use Only.
CAUTION:
Retain the instructions for future use.
Model # SRPH02-XXXX
Master Contract#: 63135A&B
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
Advertisement
Table of Contents
Related Manuals for Napoleon SRPH02-XXXX
Summary of Contents for Napoleon SRPH02-XXXX
- Page 1 WARNING For Outdoor Use Only. CAUTION: Retain the instructions for future use. Model # SRPH02-XXXX Master Contract#: 63135A&B Read the instructions before use. This appliance must be installed in Owner’s Manual accordance with such regulations as are in force.
-
Page 2: Specifications
PRECAUTIONS DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. WARNING: Improper installation, adjustment, alteration, services or maintenance can cause injury, death or property damage. - Page 3 PRECAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: The installation must conform with local codes Any guard or other protective device or, in the absence of local codes, with the removed for servicing the heater must be National Fuel Gas Code, ANSI Z223.1/NFPA 54, replaced prior to operating the heater.
- Page 4 PRECAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
-
Page 5: Warnings And Cautions
WARNINGS AND CAUTIONS PRECAUTIONS PRECAUTIONS PRECAUTIONS PRECAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This heater is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection. -
Page 6: Package Content
PACKAGE CONTENT Part Description Quantity Part Description Quantity Regulator & gas hose 1 pc Fixing chain 1 pc 1 pc Decorative cap Reflector 1 pc 1 pc Head assembly 1 pc Pole 1 pc Gas cylinder cover 1 set Pole support... -
Page 7: Hardware Contents
HARDWARE CONTENTS Part Description Quantity Picture M4X8 Screw 5 pcs 4 mm Washer 5 pcs M5X8 Screw 6 pcs 5 mm Washer 6 pcs 6 mm Washer 6 pcs M6 Nut 5 pcs M6X70 Double sided bolt 3 pcs M6X55 Double sided bolt 1 pc Decorative nut 1 pc... - Page 9 Attach the head assembly (C) to the pole (D) by inserting regulator & gas hose (A) through it, secure it with M4 x 8 screw (AA) and 4mm washer (BB). sided sided bolt...
-
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS Fig. 5 Step 5: Insert M6 x 55 double sided bolt (HH) through the central hole of the reflector (B). Attach it with M6 nut (FF). Hardware Used HH M6X55 Double sided bolt FF M6 Nut Fig. 6 Step 6: Attach the reflector (B) to the M6 x 70 double sided bolt (GG) with M6 nut (FF) - Page 11 ASSEMBLY INSTRUCTIONS Step 7: Fig. 7 Attach the decorative cap (H) to the reflector (B) with decorative nut (II). Fig. 7 Fig. 8 Step 8: the pole support (F) as indicated. Place cylinder inside the pole support (F) and fix it with fixing chain (G). Fig.8. Attach the regulator to the cylinder.
- Page 12 connections at the factory for leakage. To check the connection at the gas hose/regulator/cylinder. loosen and there is still a leak, please call customer service: 1-800-537-8484...
-
Page 13: Operation
OPERATION WARNING: DO NOT ATTEMPT TO OPERATE HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS. FAILURE TO DO SO CAN RESULT IN PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH. ARNING Before turning gas supply ON FOR YOUR SAFETY: If at any time you are unable to Your heater was designed and approved for OUTDOOR light burner and smell gas, wait 5 USE ONLY. - Page 14 OPERATION 4) Once the pilot is lit, continue to keep the control knob depressed for at least 30 seconds, After 30 seconds Yellow Tip release control knob. Primarily Blue Flame 5) If pilot does not stay lit, repeat steps 3 and 4. 6) If pilot still does not stay lit, then: a) Push in gas control knob and turn counter clockwise to Emitter Screen...
- Page 15 OPERATION CAUTION : AVOID INHALING FUMES EMITTED FROM THE HEATER'S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES. THE HEATER SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: The burner may be noisy when initially turned on.
-
Page 16: Locating Header For Use
LOCATING HEADER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas. - Page 19 Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484 or email: ps@frontgate.com Specialists are available weekdays 8:00 AM to 8:00 EST or Saturdays 9:30 AM to 6:00 PM.
- Page 20 SRPH02-XXXX color material & base p o l e & w h e e l s reflector material & base reflector pole & w h eels 1. 1PC pole w/o wheels □ 1. Steel w/ bigger base 1. 1PC reflector □...
