_ REMOVAL OF THE CONCORD REVERSO

Always remove the CONCORD REVERSO with no child in it.
4a For easy removal of the CONCORD REVERSO from the vehicle:
Rotate the control for the set inclination (03) so that the seat inclination fully in and lock the
support leg (05) in the highest position.
4b Subsequently, release both ISOFIX connectors (10) by pulling on the unlock belts (09) on both
sides of the CONCORD REVERSO.
4c Lift the CONCORD REVERSO forwards from the vehicle seat and out of the vehicle.
24
_ CARE INSTRUCTIONS
Light contamination can be removed using a moist cloth.
The cover can be removed and washed at 30 °C.
Before washing, remove the back cushion from the polystyrene body from the cover of the baby
insert (07).
Allow the cover to completely dry before fitting it.
5a Begin by fitting the cover in the foot area and pull the cover rearwards and upwards over the
shoulder area. The cover must be placed in the fixing channel between the polystyrene part and
metal frame. Subsequently, from the front, pull the cover over the head support (01).
5b Pull the cover of the baby insert (07) over the polystyrene body, beginning at the foot area and
close all fasteners at the rear.
The cover material colour may run slightly when wet, in particular during washing.
Do not use solvents on the cover!
25
