Clarion ARX850z Service Manual

■

SPECIFICATIONS

FM tuner
Frequency range: 87.9MHz to 107.9MHz
Usable sensitivity: 11dBf
50dB quieting sensitivity:
17dBf
Alternate channel selectivity:
75dB
Stereo separation(1kHz):
35dB
Frequency response( ± 3dB):
30Hz to 15kHz
AM tuner
Frequency range: 530kHz to 1710kHz
Usable sensitivity: 25
Tape deck
Wow & flutter(WRMS): 0.06%
Channel separation(1kHz):
45dB
Frequency response( ± 3dB):
120
70
S/N ratio: 70
Dolby NR off
Dolby B NR
Dolby C NR
Audio
Maximum power output:
180W(45W
Continuous average power output:
17W
20Hz to 20kHz,1%THD
Clarion Co., Ltd.
Export Division - 22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150-8335 Japan
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: 048-443-1111 FAX:048-433-6996
μ V
μ s(Normal)
30Hz to 18kHz
μ s(CrO2,FeCr,Metal)
30Hz to 20kHz
s(CrO2,FeCr,Metal)
μ
58dB
67dB
74dB
× 4ch)(EIAJ)
× 4,into 4 Ω ,
Tel: 03-3400-1121
Service Manual
AM/FM Cassette Player with
CD/MD Changer Control
Model
(PE-1637B)
Bass control action(30Hz):
Treble control action(10kHz):
Line output level(0VU tape):
General
Power supply voltage: 14.4V DC(10.8 to 15.6V allowable)
Current consumption: Less than 15A
Speaker impedance:
Dimensions(mm):
Weight:
※ Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation
Dolby and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
※ Specifications and design are subject to change with-
out notice for further improvement.
■ NOTE
※ We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure , please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
■ COMPONENTS
PE-1637B-A
Main unit
- 1 -
Published by Service Dept.
298-5718-00 Jan.1999 P
Printed in Japan
± 15dB
± 10dB
1.6V
negative ground
4 (4 to 8 allowable)
Ω Ω Ω
Source unit
178(W) 50(H) 155(D)
× ×
Remote control unit
44(W) × 110(H) × 27(D)
Source unit 1.6kg
Remote control unit
30g(including battery)
−−−−−
ARX8570z
