Panasonic cs-s9pkv Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Air Conditioner
  5. cs-s9pkv
  6. Service manual

Panasonic cs-s9pkv Service Manual

Hide thumbs Also See for cs-s9pkv:
Table of Contents

Advertisement

Quick Links

This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
WARNING
PRECAUTION OF LOW TEMPERATURE
Indoor Unit
CS-S9PKV
CS-S12PKV
CS-S18PKV
CS-S24PKV
CS-S28PKV
© Panasonic Corporation 2013
Order No: PAPAMY1303008CE
Outdoor Unit
CU-S9PKV
CU-S12PKV
CU-S18PKV
CU-S24PKV
CU-S28PKV
Destination
Latin America
