3.1 Power On/Off

Before you power on the unit, please make sure all the connection is good.

3.1.1 Power on

Step1: connect with the source power; switch on the power button near the power port on the rear panel
Step2: the device will be loaded, and the power indicator will display blue
Step3 before start, a WIZZARD window will be pop-up and show some information about time zone，time setup，network
configuration, record configuration and disk management. User can setup here and refer to the concrete setup steps from the
corresponding chapters. If users don't want to setup Wizard, please click Exit button to exit.
After the device power on, if there is no menu or only has live image display, user can long press ESC button to switch.
Notice: this serial device can only display menu on VGA monitor or BNC monitor at one time, if there is live image display without
menu display, please check up whether other device has menu display firstly, or long press ESC key to wait for login dialog box
to appear. Long press ESC key can switch the output between BNC and VGA.

3.1.2 Power off

User can power off the device by using remote controller、keyboard and mouse.
By remote controller:
Step1: press Power button to see the Shut down window. After clicking OK, the unit will power off after a while.
Step2: disconnect the power
By keyboard and mouse:
Step1: enter into
Step2: click OK to power off.
Step3: disconnect the power.
Digital Video Recorder User Manual
3

Basic Function Instruction

Menu, then select "System Shut Down" icon, the Shut down window will appear
