Set and User Program

Set
"set"
A is analogous to a single accordion.
Switching sets is analogous to putting down one accordion and
picking up a different one.
When you do so, the right hand register buttons and left hand
register buttons operate to change registers (change the
combination of reeds) as on an acoustic instrument.
When you want to switch sounds, you can use this as if you were
playing an acoustic accordion.
"Using Sets"
For details, (p. 33).
User Program
The selected register is maintained even when you change sets;
however for user programs, the register number of each selected
part and the on/off status of the part can also be remembered.
User programs are convenient to use during a live performance,
since they let you instantly switch settings that would otherwise
require multiple button presses to specify, such as changing sets or
registers.
For details, "Working with User Programs"
Sets and user programs are similar in that they contain sound
settings, but because there are several differences in the contents
of the settings that can be stored, there are differences in what
happens when you press a register button.
You can use either sets or user programs as appropriate for your
needs.
Saved parameters
Parameter
SetComon (Set Common) parameters
(p. 70)
Accordion parameters (p. 45)
Bass parameters (p. 49)
Free Bass parameters (p. 51)
Orchestra/Organ parameters
(p. 53, p. 56)
Orchestra Bass parameters (p. 57)
Orchestra Chord parameters (p. 60)
Orchestra Free Bass parameters (p. 63)
Drum parameters (p. 66)
Right Hand Mode parameters (p. 69)
5
Current part of the left hand part (*)
5
Current part of the right hand part (*)
5
On/off status of the left hand part
5
On/off status of the right hand part
5
Register number selected for each part
5
Name of the user program
5
Link to the user program's audio file
5
Volume of the audio file
5
Scale tuning setting
5
Transpose setting
5
Bass To Treble on/off
5
Right hand octave setting
* A part whose register changes when you press a register button.
(p. 39).
Set User Program
( (
( (
( (
( (
( (
( (
( (
( (
( (
( (
(
—

The Folder Structure of a USB Flash Drive

Sets and user programs can be exported as a backup file to the
MySET folder or MyUPG folder of your USB flash drive.
Audio-recorded WAV files are saved in the MyREC folder of the USB
flash drive.
MySET Folder
(
Exported SET files are saved in this folder.)
SET_ALL.FR4
SET_001.ST4
MyUPG Folder
(
Exported User Program files are saved in this folder.)
UPG_ALL.UPA
001_UPG_BANK.UPB
001_001_UPG.UPG
MyREC Folder
(
Audio recorded files are saved in this folder.)
Song1.wav
Song2.wav
Song3.wav
Introduction
5
