See Warranty on page 2 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Pressure
Power Switch
Gauge
Model HDR650

Specifications

Max Pressure . . . . 150 psi
Features . . . . . . . . Built-in Pressure Gauge
Compact Size
Cooling fan
Weight . . . . . . . . . 1.5 lbs.
Voltage . . . . . . . . . 12V, DC
Air Outlet . . . . . . . High Pressure Chuck
Description
The 12-volt inflator comes with inflation
nozzles and needle. The inflator can be
used for emergency roadside tire inflation
and to inflate bike tires, soccer balls, beach
balls and other sporting equipment.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit.

Safety Guidelines

This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
an imminently hazardous situation
which, if not avoided, WILL result in
death or serious injury.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2007
a potentially hazardous situation which,
if not avoided, COULD result in death or
serious injury.
a potentially hazardous situation which,
if not avoided, MAY result in minor or
moderate injury.
important information, that if not
followed, may cause damage to
Power
equipment.
Cord

General Safety

Completely read the manual
included with this product
carefully. Be thoroughly
familiar with the proper use
of the unit.
Any misuse of unit could
cause property or
equipment damage and/or
personal injury.
CALIFORNIA PROPOSITION 65
or its power cord contains lead, a
chemical known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
inflator unattended while the unit is
running.
Never exceed the
recommended pressure for any
inflatable object. Do not over
inflate objects. Over inflation could cause
property damage and/or personal injury.
adapter must be locked to secure the
inflation accessories. Use extreme caution
when using inflation accessories.
Danger
indicates
car in park; set the emergency brake; and
chock the wheels before using the
inflator or property damage and/or
personal injury could occur.
12-Volt Inflators
Warning
indicates
separate pressure gauge to check the ac-
tual pressure in tires and in low pressure
inflatable objects.
Caution
indicates
for 20 minutes after 20 minutes of
continuous operation. The Inflator is not
designed to operate continuously for
more than 20 minutes.
Notice
indicates
inflator on high pressure tires used on
large trucks, trailers or tractors. The
inflator is not designed to operate for
the length of time necessary to inflate
these tires.
universal adapter touches the core or tire
MANUAL
valve stem.
Operation
TIRES
1. Remove valve stem cap.
2. Attach the universal adapter from the
This
product
Do not
leave the
Figure 1
The
universal
3. Plug power cord into 12-volt DC power
Always
put the
volt DC power outlets rated 15 amps or
higher. Do not use with older 8 amp
cigarette lighter receptacles.
4. Turn power switch on.
HDR650
inflator to the valve stem with the
lever in the up position. Be sure to
press universal adapter down over
valve stem threads completely. When
universal adapter is firmly in place,
press locking lever down to lock onto
valve stem (See Fig. 1).
Lock
Universal
Adapter
Valve Stem
outlet.
IN720400AV 6/07
Always
use a
Inflator
must cool
Do not
use
Make
sure the
For use
with 12-
