Specifications

Recording
Storage media:
File format:
A/D converter:
Sampling rate:
Recording modes/Bit rate:
Input
Type:
Input level:
Input connector:
Headphone/Line Output
Connector:
Maximum level:
Audio Performance
Frequency response:
Signal to Noise ratio:
Distortion:
Time Code
Connector:
Signal voltage:
Input impedance:
Format:
Battery Power/Life
Power consumption:
Battery type:
AAA Lithium:
AAA alkaline
Operating temperature range
Celsius:
Fahrenheit:
Dimensions and Weight
Dimensions:
Weight:
*microSDHC Logo is a trademark of SD-3C, LLC
Rio Rancho, NM
microSDHC memory card*
.wav files (BWF - Broadcast Wave File)
24-bit (with additional 8 bits for wav format
compatibility)
48 kHz
• HD mono mode: 192 kb/s
• Split gain mode: 384 kb/s
Analog mic/line level compatible;
servo bias preamp for 2V and 4V lavaliere
microphones
• Dynamic mic: 0.5 mV to 50 mV
• Electret mic: Nominal 2 mV to 300 mV
• Line level: 17 mV to 1.7 V
TA5M 5-pin male
3.5 mm mini jack; TR
-3 dBu (575 mV RMS)
20 Hz to 20 kHz; +0.5/-1.5 dB
• HD mono mode: 105 dB A-weighted
• Split gain mode: 80 dB A-weighted
< 0.035%
5-pin LEMO
0.5 Vp-p to 5Vp-p
10 k Ohms
SMPTE 12M - 1999 compliant
300 mW
AAA Lithium non-rechargeable
(recommended)
6.5 hours typical
2 to 3 hours; varies with brand
-20 to 50
-5 to 122
Inches: 2.37H x 2.14W x 0.67D
Millimeters: 60H x 54W x 17D
71 grams (2.5 ozs.) w/ AAA Lithium battery

Available Recording Time

Using a microSDHC memory card, the available re-
cording times are as follows. The actual time may vary
slightly from the values listed in the tables.
HD mono mode
Size Hrs:Min
8GB 11:12
16GB 23:00
32GB 46:07
Portable Digital Recorder
Split gain mode
Size Hrs:Min
8GB 5:36
16GB 11:30
32GB 23:03
