Summary of Contents for Magner 150
-
Page 2: Table Of Contents
User’s Manual MAGNER150 - Contents – Important Safety Precautions .................... 4 Warning ..........................4 1. START 1-1. Packing List ...................... 5 1-2. Options ......................5 1-3. Appearance ....................... 6 2. BASIC OPERATION 2-1 Self-Diagnosis ....................7 2-2. Counting Notes ....................8 2-3. - Page 3 User’s Manual MAGNER150 6. SERIAL PRINTER 6-1. Descriptions of Serial Printer ............... 31 6-2. Descriptions of Serial Port ................31 6-3. How to set the Serial Printer ................. 32 6-4. Descriptions of Menu ..................33 6-5 Print the receipt ....................33 6-6.
-
Page 4: Important Safety Precautions
User’s Manual MAGNER150 - Important Safety Precautions - Do not plug several products in one multi-outlet. Do not bend the cable by force or leave it under any heavy object. Install the machine on the stable surface Unplug the machine before it is moved Do not pull the cable it unplugged. -
Page 5: Start
User’s Manual MAGNER150 1. START 1-1. Packing List MAGNER150 Manual Power Cable 1-2. Options External Display Serial Print cable RS232C cable - 5 -... -
Page 6: Appearance
User’s Manual MAGNER150 1-3. Appearance - 6 -... -
Page 7: Basic Operation
User’s Manual MAGNER150 2. BASIC OPERATION 2-1. Self-Diagnosis Plug the power cable into the machine. The machine starts self-diagnosis and check- Turn on the power switch. lists are shown on the display. MAGNER150 M A G N E R 1 5 0 S E R I E S C F F U N C T I O N : Y E S S E R I A L N U M B E R : Y E S L O C A L C U R R E N C Y : Y E S... -
Page 8: Counting Notes
User’s Manual MAGNER150 2-2. Counting Notes Display shows as below. Press CURRENCY key and CURRENCY select any mode you will. C O U N T R J P - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B 1 0 0 - - -... -
Page 9: Display Function
User’s Manual MAGNER150 2-3. Display Function Operation Mode Use of Reject Pocket Counterfeit Detection Activation Number of notes M i x R J P - - - Stacker - - - - - - - - - - - - - - - - - - - - Pocket Number of notes on Reject Pocket... -
Page 10: Operation Key Function
User’s Manual MAGNER150 2-4. Operation Key Function ▲/+10 When press and hold down, enter User Counterfeit detection function key. setting Mode and Serial Print Mode. CURRENCY Choose currency BATCH Batch function Key. When press and hold down the key, the function is released. PRINT Show the denomination information. -
Page 11: Basic Mode
User’s Manual MAGNER150 3. Basic Mode 3-1. Count Mode Display shows as below. Press CURRENCY key and CURRENCY select any mode you will. C O U N T R J P - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B 1 0 0 - - -... - Page 12 User’s Manual MAGNER150 Gap Adjustment If CIS skew error or Jam error occurs frequently, adjust the GAP wider by turning the Gap Adjustment Knob clockwise slightly. In serial number print mode, if the inserted gap is narrow, display shows as below. This mark will be blinking.
- Page 13 User’s Manual MAGNER150 Level key function DDL means Double Detection Level. C O U N T R J P - - - User can select the level and the range from 1 - - - - - - - - - - - - - - - - - - - - to 9.
-
Page 14: Euro Mode
User’s Manual MAGNER150 3-2. Euro Mode Display shows as below. Select Euro currency pressing CURRENCY CURRENCY key. M i x R J P - - - - - - - - - - - - - - - - - - - - - - - Press the MODE key and MODE select operation mode. -
Page 15: Operation Mode I
User’s Manual MAGNER150 4. Operation Mode I 4-1. Batch Mode Display shows as below. If you want to activate Batch BATCH function, press BATCH key. But M i x R J P Display has no change. - - - - - - - - - - - - - - - - - - - - After activating Batch function, if you press BATCH key again, you can select Batch Number. -
Page 16: Add Mode
User’s Manual MAGNER150 4-3. ADD Mode Display shows as below. When press and hold ADD key, you can enter ADD Mode or GRAND TOTAL Mode. S E L E C T K E Y To enter ADD Mode, press +1 key. + 1 0 - >... - Page 17 User’s Manual MAGNER150 When count the notes again When remove the notes from stacker again M i x R J P M i x R J P - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - c u r r e n t A d d...
-
Page 18: Grand Total Mode
User’s Manual MAGNER150 4-4. Grand Total Mode Display shows as below. When press and hold ADD key, you can enter ADD Mode or GRAND TOTAL Mode. S E L E C T K E Y To enter Grand Total Mode, press + 1 0 - >... - Page 19 User’s Manual MAGNER150 If you want to save SubTotal 1, press and hold down ADD Key again. M i x R J P - - - - - - - - - - - - - - - - - - - - S E L E C T K E Y S u b T o t a l A D D - >...
- Page 20 User’s Manual MAGNER150 M i x R J P If press +10 key, Grand Total value is - - - - - - - - - - - - - - - - - - - - cleared. G r a n d T o t a l - - - - - - - - - - - - - - - - - - - - B 1 0 0 G .
- Page 21 User’s Manual MAGNER150 Receipt of Operation, ADD and Grand Total Mode User can print the counted result to printer. There are three types of Receipt. Normal Operation Mode In ADD Mode Ex) Mix Mode In Grand Total Mode During counting SubTotal xx, if press After saving SubTotal xx, if press PRINT PRINT key, the receipt for SubTotal is key, the receipt for Grand Total xx is...
- Page 22 User’s Manual MAGNER150 Verify function During counting in ADD or GTOTAL mode, use can verify counting result which already counted after activating ADD or GTOTAL function or new bundle of note which is independent with ADD or GTOTAL counting result. EX) ADD mode After activate ADD function, use counts 1200 notes.
-
Page 23: Operation Mode
User’s Manual MAGNER150 5. Operation Mode II COUNTING FUNCTIONS Mix MODE Count all denomination of selected currency. DISPENSER User can count notes as their wish. MODE (Option) The machine saves information from first inserted note. SP MODE (Different notes will be separated into the Reject Pocket) SP-ver MODE Sp mode plus discrimination of old and new version notes. -
Page 24: Mix Mode
User’s Manual MAGNER150 5-1. Mix Mode Display shows as below. Select currency pressing CURRENCY CURRENCY key. M i x R J P - - - - - - - - - - - - - - - - - - - - Press the MODE key and MODE choose Mix mode. -
Page 25: Separate Mode (Sp Mode)
User’s Manual MAGNER150 5-3. Separate Mode (SP Mode) Press CURRENCY R J P CURRENCY choose the mode, you want. - - - - - - - - - - - - - - - - - - - - Press the MODE key and MODE choose SP mode. -
Page 26: Single Mode
User’s Manual MAGNER150 5-6. Single Mode (SG Mode) Press CURRENCY CURRENCY S G $ 1 0 0 R J P choose the mode, you want. - - - - - - - - - - - - - - - - - - - - Press the MODE key and MODE choose SG mode. -
Page 27: Dir-Sf Mode
User’s Manual MAGNER150 5-9. Dir-SF Mode Press CURRENCY key and D i r - S F R J P choose the mode, you want. - - - - - - - - - - - - - - - - - - - - CURRENCY Press the MODE key and choose Dir-MO mode... - Page 28 User’s Manual MAGNER150 Print the Error Report When the counted notes are rejected, user can receive the error report by the LCD Display or printing receipt. - Error report on the LCD Display. When the notes are rejected, do not remove the note from reject pocket, press and hold down MODE key.
-
Page 29: Serial Number Print Mode
User’s Manual MAGNER150 5-11. Serial Number Print Mode Press CURRENCY key and S e r i a l R J P choose the mode, EURO or - - - - - - - - - - - - - - - - - - - - CURRENCY Press the MODE key and choose Serial mode... - Page 30 User’s Manual MAGNER150 How to store Serial Number to PC MAGNER150 allows storage of Serial Number to PC by special PC program, Serial Number Manager. If you want to use Serial Number Manager, please contact manufacture. CF function in Serial Number Print Mode Please note.
-
Page 31: Serial Printer
User’s Manual MAGNER150 6. SERIAL PRINTER 6-1. Descriptions of Serial Printer (RS232c) Emulation MODE : EPSON or STAR ( EPSON Emulation MODE is a Default Value of Factory ) Baud Rate : 2,400 bps ~ 115,200 bps ( 115,200 bps is a Default Value of Factory. ) Data Bits : 8 bits Stop Bits : 1 bit Handshaking : DTR/DSR... -
Page 32: How To Set The Serial Printer
User’s Manual MAGNER150 6-3. How to set the Serial Printer Press and hold down +10 key. S e r i a l R J P - - - - - - - - - - - - - - - - - - - - +10 ->... -
Page 33: Descriptions Of Menu
User’s Manual MAGNER150 6-4. Descriptions of Menu S E R I A L P R I N T E R M E N U ( 1 / 2 ) S E R I A L P R I N T E R M E N U ( 2 / 2 ) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... -
Page 34: Form Of The Receipt
User’s Manual MAGNER150 After counting, press and hold down PRINT key, The machine prints the receipt. U S D V A L U E C O U N T I N G - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - : X X X , X X X | $ 1 0 : X X X , X X X |... -
Page 35: User Setting Mode
User’s Manual MAGNER150 7. USER SETTING MODE 7-1. How to set the User Setting Mode Press and hold down +10 Key. S e r i a l R J P - - - - - - - - - - - - - - - - - - - - +10 ->... -
Page 36: Descriptions Of Menu
User’s Manual MAGNER150 7-2. Descriptions of Menu U S E R S E T T I N G M O D E ( 1 / 3 ) U S E R S E T T I N G M O D E ( 2 / 3 ) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 37 User’s Manual MAGNER150 16. CF KEY - EXCEPTION NORMAL: Machine detects all counterfeits. EXCEPTION: Machine detects counterfeits except special note or denomination. 17. SERIAL CF MODE- ON Activate or inactivate CF function in Serial Mode. This function is only available with special hardware. If you want to use counterfeit detection in Serial Number Print Mode, please contact manufacture.
- Page 38 User’s Manual MAGNER150 How to input ID W R I T I N G U S E R ’ s I D 1. Press MODE key to move the “>>” make - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - to select “2.
-
Page 39: Specification Of The Magner150
User’s Manual MAGNER150 SPECIFICATION OF THE MAGNER150------------------------------------ -Technical Specification Available currencies EURO, USD, LOCAL(OPTION) Dimension(mm) 330(W)×350(D)×370(H) Display 4.1 inch Graphic LCD Weight Approx. 16 Kg Denomination Detection Full Line Image Sensor Countable Notes UV, FL, MG (Magnetic 60 × 90mm ~ 100 × 180mm Counterfeit Detection Size Thread Detection), IR... -
Page 40: Error Code - Count Error
User’s Manual MAGNER150 - ERROR CODE AND DISPLAY MESSAGE ERROR Procedure for removing the DISPLAY MESSAGE CAUSE OF ERROR cause of error CODE 1. Remove notes from the HOPPER, REJECT and STACKER POCKET. 2. Open rear cover and remove notes E001 Jam Error Jamming in the machine... -
Page 41: Value Error
User’s Manual MAGNER150 - ERROR CODE AND DISPLAY MESSAGE FOR VALUE ERROR Procedure for removing the DISPLAY MESSAGE CAUSE OF ERROR cause of error CODE E101 Value Error ( E101 ) Skew ( Left ) E102 Value Error ( E102 ) Skew ( Right ) E103 Value Error ( E103 ) -
Page 42: Uv Error / Mg Error
User’s Manual MAGNER150 - ERROR CODE AND DISPLAY MESSAGE FOR UV ERROR Procedure for removing the DISPLAY MESSAGE CAUSE OF ERROR CODE cause of error E201 E-UH UV1 high level error E202 E-UL UV1 low level error Suspect Note. E203 E-BH UV2 high level error Check... -
Page 43: Cf Error / Ir Error
User’s Manual MAGNER150 - CF ERROR CODE FOR COUNTING ERROR Procedure for removing the DISPLAY MESSAGE CAUSE OF ERROR CODE cause of error E221 E-C1 Abnormal note is mixed E222 E-C2 A Note is skewed E223 E-C3 A Note with Hole is mixed Restart counting operation. -
Page 44: Regular Cleaning Of The Machine
User’s Manual MAGNER150 REGULAR CLEANING OF THE MACHINE-------------------------------------------- The machine has a many sensitive sensor to perform high technology functions, for example counterfeit detection, denominations, recognition of serial number and etc. Users are recommended to clean the machine sensors at least once a week. Refer to following section and clean the machine regularly. - Page 45 User’s Manual MAGNER150 Rev 1.3 2008. 02. 18 - 45 -...
