ORION TELESCOPES & BINOCULARS GoScope II Operating And Assembly Manual

Orion GoScope
Orion Quick Start Assembly & Operating Guide
Thank you for your purchase of an Orion 70mm GoScope
II. Use these quick instructions to get started on a high-
powered exploration of the world around you and into the
depths of Outer Space! More learning materials, including
monthly sky maps, can be found in Orion's Community page
at OrionTelescopes.com, including articles on observing the
planets and locating deep sky objects. Also see the support
page for the GoScope II on the website for updates and tips.
SOLAR WARNING: Never Use the GoScope II, or its
finderscope, to look at the Sun without a proper, safe
solar filter. Using a telescope or binocular to observe
the Sun may cause instant eye damage or blindness.
Use under appropriate adult supervision.
Providing Exceptional Consumer Optical Products Since 1975
InStRuCtIOn MAnuAl
II 70mm Refractor
™
#10034

Components

• Dust Covers
• Objective Lens (70mm diameter and 400mm focal length)
• Focus Knob
• Focus Drawtube
• 45 Degree Diagonal
• Eyepiece (two included: a 20mm and a 10mm); also called
an ocular
• Tripod Adaptor Block (on telescope)
• Tripod Adaptor Screw (on tripod)
• Tripod Pan-Tilt Handle & Up-Down (or Tilt) Locking Screw
• Tripod Center Column (adjustable height)
• Tripod Legs (adjustable height)
• Center Column Locking Screw
• Tripod Leg Cam Locks
• Azimuth (Left-Right) Locking Screw
• Backpack

Assembly

Step 1: Unpack Your GoScope
Figure 1: Unpacked; save the lens caps and packaging.
