- Page 1 ACKAGE UMPS FORM NO. P22-764 REV. 3 Supersedes Form No. P22-764 Rev. 2 RQNA-B HIGH EFFICIENCY 13-SEER SERIES NOMINAL SIZES 2-4 TONS [7.03-14.07 kW]...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Unit Features & Benefits ................3-4 Model Identification Options ................5-6 General Data RQNA-B Series ..................7-8 General Data Notes ..................9 Performance Data RQNA-B Series ..................10-14 Airflow Performance RQNA-B Series ..................15-16 Electrical Data RQNA-B Series ..................17 Electric Heater Kits ..................18-19 Dimensional Data ..................20-21 Typical Installations ..................22 Accessories ....................23-30... -
Page 3: Unit Features & Benefits
UNIT FEATURES & BENEFITS—RQNA-B These quality features are included in the Ruud Outdoor Package Heat Pumps... -
Page 4: Unit Features & Benefits
UNIT FEATURES & BENEFITS—RQNA-B SERIES Features Below Correspond to Photos on Page 3 1. All models feature Copeland ® Scroll ® compressors for 8. Refrigerant connections are conveniently located for maximum efficiency and quiet operation. easy service diagnostics. 2. Louvered condenser compartment for protecting the 9. -
Page 5: Model Identification Options
036 = 36,000 [10.55] 042 = 42,000 [12.31] 048 = 48,000 [14.07] Design Series A = 1st Design Efficiency Designation N = 13 SEER High Efficiency Product Classification Q = Package Heat Pump Tradebrand R = Ruud [ ] Designates Metric Conversions... - Page 6 OPTIONS—RQNA-B SERIES Instructions for Factory Installed Option(s) Selection Note: Two characters following the model number will be utilized to designate a factory-installed option or com- bination of options. If no factory option(s) is required, nothing follows the model number. Step 1. After a basic rooftop model is selected, choose a two-character option code from the FACTORY INSTALLED OPTION SELECTION TABLE.
-
Page 7: General Data Rqna-B Series
GENERAL DATA—RQNA-B SERIES NOMINAL SIZES 2-4 TONS [7.03-14.07 kW] Model RQNA-B Series B024JK B030JK B036CK B036JK Cooling Performance CONTINUED Gross Cooling Capacity Btu [kW] 24,400 [7.15] 31,400 [9.2] 36,600 [10.72] 36,600 [10.72] EER/SEER 11/13 11/13 11/13 11/13 Nominal CFM/ARI Rated CFM [L/s] 800/800 [378/378] 1000/1050 [472/495] 1200/1200 [566/566]... -
Page 8: Rqna-B Series
GENERAL DATA—RQNA-B SERIES NOMINAL SIZES 2-4 TONS [7.03-14.07 kW] Model RQNA-B Series B042CK B042JK B048CK B048JK Cooling Performance Gross Cooling Capacity Btu [kW] 44,500 [13.04] 44,500 [13.04] 50,000 [14.65] 50,000 [14.65] EER/SEER 11/13 11/13 11/13 11/13 Nominal CFM/ARI Rated CFM [L/s] 1400/1400 [661/661] 1400/1400 [661/661] 1600/1600 [755/755]... -
Page 9: General Data Notes
GENERAL DATA—RQNA-B SERIES NOTES: 1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and includes the effect of fan motor heat. Units are suitable for operation in CFM range shown in airflow tables. -
Page 10: Rqna-B Series
SYSTEMS PERFORMANCE—RQNA-B SERIES COOLING PERFORMANCE DATA—RQNA-B024 ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C] CFM [L/s] 900 [425] 800 [378] 700 [330] 900 [425] 800 [378] 700 [330] 900 [425] 800 [378] 700 [330] DR ➀... -
Page 11: Performance Data
SYSTEMS PERFORMANCE—RQNA-B SERIES COOLING PERFORMANCE DATA—RQNA-B030 ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C] CFM [L/s] 1180 [557] 1050 [496] 920 [434] 1180 [557] 1050 [496] 920 [434] 1180 [557] 1050 [496] 920 [434] DR ➀... -
Page 12: Performance Data
SYSTEMS PERFORMANCE—RQNA-B SERIES COOLING PERFORMANCE DATA—RQNA-B036 ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C] CFM [L/s] 1350 [637] 1200 [566] 1050 [496] 1350 [637] 1200 [566] 1050 [496] 1350 [637] 1200 [566] 1050 [496] DR ➀... - Page 13 SYSTEMS PERFORMANCE—RQNA-B SERIES COOLING PERFORMANCE DATA—RQNA-B042 ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C] CFM [L/s] 1580 [746] 1400 [661] 1220 [576] 1580 [746] 1400 [661] 1220 [576] 1580 [746] 1400 [661] 1220 [576] DR ➀...
-
Page 14: Rqna-B Series
SYSTEMS PERFORMANCE—RQNA-B SERIES COOLING PERFORMANCE DATA—RQNA-B048 ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C] CFM [L/s] 1800 [850] 1600 [755] 1400 [661] 1800 [850] 1600 [755] 1400 [661] 1800 [850] 1600 [755] 1400 [661] DR ➀... -
Page 15: Airflow Performance Rqna-B Series
AIRFLOW PERFORMANCE—RQNA-B SERIES... -
Page 16: Rqna-B Series
AIRFLOW PERFORMANCE—RQNA-B SERIES... -
Page 17: Electrical Data Rqna-B Series
ELECTRICAL DATA—RQNA-B SERIES ELECTRICAL DATA – RQNA-B SERIES -B024JK -B030JK -B036CK -B036JK -B042CK -B042JK -B048CK -B048JK Unit Operating 187-253 187-253 187-253 187-253 187-253 187-253 187-253 187-253 Voltage Range Minimum Circuit Ampacity 17/17 21/21 16/16 24/24 25/25 32/32 25/25 37/37 Minimum Overcurrent 20/20 25/25 20/20... -
Page 18: Electric Heater Kits
ELECTRIC HEATER KITS—RQNA-B SERIES Unit Model Application Electric Heater Kit Models RXQJ-A05J (208-240 volt, 1-ph, 5kW) RQNA-B024JK RXQJ-A10J (208-240 volt, 1-ph, 10kW) RXQJ-A05J (208-240 volt, 1-ph, 5kW) RQNA-B030JK RXQJ-A10J (208-240 volt, 1-ph, 10kW) RXQJ-A10J (208-240 volt, 1-ph, 10kW) RQNA-B036JK RXQJ-A15J (208-240 volt, 1-ph, 15kW) -
Page 19: Electric Heater Kits
ELECTRIC HEATER KITS—RQNA-B SERIES... -
Page 20: Dimensional Data
UNIT DIMENSIONS—RQNA-B SERIES UNIT DIMENSIONS SELF-CONTAINED AIR CONDITIONERS OUTDOOR FAN GRILLE AND COMPRESSOR ACCESS CONTROL FILTER ACCESS ACCESS PANEL PANEL (FOR UNIT MOUNTED FILTER ACCESSORY) LIQUID PRESSURE 30% 2% SERVICE PORT OUTDOOR COIL PROTECTIVE GRILLE SUCTION PRESSURE 21% 2% SERVICE PORT THREADED PVC CONDENSATE DRAIN CONNECTION ( "... -
Page 21: Back View
UNIT DIMENSIONS—RQNA-B SERIES SIDE VIEW SIDE VIEW OUTDOOR COIL PROTECTIVE FILTER ACCESS PANEL (FOR UNIT GRILLE THERMOSTAT MOUNTED FILTER ACCESSORY) WIRE ENTRANCE " [28.6 mm] " [643 mm] " [259 mm] " [129 mm] " ELECTRICAL BLOWER/ [1332 mm] " POWER EVAPORATOR [121 mm]... -
Page 22: Typical Installations
TYPICAL INSTALLATIONS [ ] Designates Metric Conversions [ ] Designates Metric Conversions... -
Page 23: Accessories
ACCESSORIES ACCESSORY EQUIPMENT Accessory Model Accessory Description Application Model No. RXQG-AAA14 (14" [356 mm] Height) Roofcurbs RQNA-B RXQG-AAA24 (24" [610 mm] Height) Supply & Return Diffusers RQNA-B RXRN-BD15 RXRE-CAA30 (3 Position) Economizers (Downflow Only) RQNA-B RXRD-CAM10 (Fully Modulating) Economizers (Sideflow Only) RQNA-B RXRD-CCM10 (Fully Modulating) RXRF-FAB1 (Motorized-35%) - Page 24 ACCESSORIES DUCT ADAPTERS RECTANGULAR TO ROUND TRANSITIONS (DOWNFLOW) RXMC-CA02 RXMC-CA03 [ ] Designates Metric Conversions...
- Page 25 ACCESSORIES FRESH AIR DAMPER FOR USE ON RQNA-B SERIES RXRF-FAA1 (Fixed - 0-35%) The 0-35% manual outside Air Damper is designed to replace the unit return air duct cover. No drilling or damper assembly is required. The amount of outside air (0-35%) is controlled by sim- ply adjusting the side damper.
- Page 26 ACCESSORIES ECONOMIZERS RXRD-CCM10 (Fully Modulating) for RQNL-B/RQPL-B Series Horizontal Application RXRD-CCM10 (Fully Modulating) Provided with enthalpy control, mixed air sensor and minimum position poten- tiometer for proportioning (modulating) the amount of fresh air. [ ] Designates Metric Conversions...
- Page 27 ACCESSORIES FILTER KIT INSTALLATION RXRY-B01 For use in either vertical or horizontal discharge. Airflow Pressure Drop, Inches W.C. [kPa] CFM [L/s] CFM [L/s] 1" Filter 2" Filter Minimum Nominal Maximum Airflow Airflow Airflow 500 [236] .02 [.0050] .03 [.0075] 510 [241] 600 [283] 660 [311] 600 [283]...
- Page 28 ACCESSORIES DUCT ADAPTER SIDEFLOW SQUARE TO ROUND TRANSITION RXMC-BA01 Adapts the side rectangular supply and return openings to 14" [356 mm] diameter round openings. Adapters provided with same finish as unit and also provided with thermal insulation.
- Page 29 ACCESSORIES Roofcurb (Sloped) RXQG-AAA14 (14" [356 mm] High) RXQG-AAA14 & RXQG-AAA24 for RQNA-B Series Heat pump models must use sloped curbs. Hinged corners make for fast, easy set-up. RXQG-AAA24 (24" [610 mm] High) Packaged Heat Pump Roofcurb Installation (Sloped) OUTDOOR FAN GRILLE AND COMPRESSOR ACCESS OUTDOOR COIL PROTECTIVE GRILLE...
-
Page 30: Accessories
ACCESSORIES ROOFCURB ADAPTERS Fabricated from galvanized steel to adapt the New cabinet to the old style curb. All are furnished with a New gasket. OLD MODEL PACKAGE OLD CURB MODEL NEW MODEL TO OLD MODEL NEW MODEL PACKAGE HEAT PUMP ROOFCURB ADAPTER HEAT PUMP SMALL CABINET... -
Page 31: Typical Wiring
WIRING SCHEMATICS—RQNA-B SERIES... - Page 32 WIRING SCHEMATICS—RQNA-B SERIES...
- Page 33 WIRING SCHEMATICS—RQNA-B SERIES...
- Page 34 WIRING SCHEMATICS—RQNA-B SERIES...
- Page 35 NOTES...
-
Page 36: Limited Warranty
Federal, State, Provincial, and Local codes, regulations, and practices. 5600 Old Greenwood Road, Fort Smith, Arkansas 72908 “In keeping with its policy of continuous progress and product improvement, Ruud reserves the right to make changes without notice.” PRINTED IN U.S.A. 8-06 DC FORM NO.
