EN
User manual
Elops 900E
Pack .ref : 2131600
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELOPS 900E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Btwin ELOPS 900E

Summary of Contents for Btwin ELOPS 900E

  • Page 1 User manual Elops 900E Pack .ref : 2131600...
  • Page 2 You must refer to the B’TWIN user guide and warranty instructions that are shared by all of our bikes and which are provided with this document. They can also be found on our website at www.btwin.com or requested at our DECATHLON stores.
  • Page 3 10 best practices for getting the most out of your electrically-assisted bicycle. pedal or you won’t get far inflate the tyres or you won’t get far > 3,5 ─ 4,5 bar < 3 bar 20° 5° inflate the tyres or you will get a flat your battery life will be reduced in cold weather 100% your battery will reach 100% capacity after 5...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PRODUCT DESCRIPTION ........6 Electrically-assisted bike technical features ......6 General operation of the electrical assistance ....6 SCREEN AND CONTROL ELEMENTS ....7 Screen data and function .............7 BATTERY AND CHARGER ........8 Precautions for use ...............9 Installing and removing the battery ........11 Recharging the Battery ............12 Maintenance and lifetime (warranty conditions) ....12 Additional precautions for use ..........13...

  • Page 6: Product Description

    PRODUCT DESCRIPTION Electrically-assisted bike technical features Rear LED light Battery and controller Beam + connectors: brakes / control screen Control screen Braking detector Front LED light Motor wiring harness Motor Pedalling detector General operation of the electrical assistance The electrically-assisted bike can be used with or without assistance by pressing the ON/OFF button. Always lock the battery with the key when in use.

  • Page 7: Screen And Control Elements

    SCREEN AND CONTROL ELEMENTS Screen data and function KM/H Power KM MAX Assist Assistance mode : Pedalling assistance: Select the assistance mode between 1 and 6 with the «+» and «-» buttons. Assist Mode 1 (by default) Maximum assistan- 6 km/h 10 km/h 14 km/h 18 km/h...

  • Page 9: Precautions For Use

    Precautions for use Do not expose to temperatures exceeding 50°C. +50° < +10°C +10°C / +50°C > +50°C Storage conditions: +10°C It is essential to store the battery charged and in a dry, cool place (between +10°C and +25°C), out of sunlight. +25°C <...
  • Page 10 Never permit children to play with or handle the battery. Do not immerse in water. Do not clean using a high-pressure washer. Rain resistant. Your battery can be completely charged and drained 500 x : 1..500 times. Hereafter, the capacity and autonomy of the battery is re- duced.

  • Page 11: Installing And Removing The Battery

    Installing and removing the battery Insertion: Prior to inserting your battery into its slot, unlock it using the key and check that there are no foreign objects or matter in the battery sheath. Then turn on the power switch. Removal: Prior to removing your battery from its slot, unlock it using the key.

  • Page 13: Additional Precautions For Use

    Additional precautions for use Always carry out maintenance operations in sufficient light. Warning, in the event of wheel removal, you must ensure the direction of rotation of your wheel is correct. Before each use you must make sure that your brakes and electric system are working properly The weight, power, manufacturing year and maximum speed are indicated on your bicycle’s frame.

  • Page 14: Maintenance

    You must refer to the B’twin user guide and warranty ins- tructions that are shared by all of our bikes and which are provided with this document. They can also be found on our website www.btwin.com or by request from our DECA- THLON stores. Prohibited: cleaning using a high-pressure jet.
  • Page 15 The rims are subject to wear which must be checked to ensure they are intact. The motorised wheel is also subject to higher stress than a standard bike wheel, and although it is reinforced, it is possible that spokes may break. If a spoke breaks, contact your DECATHLON store.

  • Page 16: Displays Error Code On The Control Screen

    Displays error code on the control screen Definition Solutions Fault code Bad connection between the control screen and Check that all connectors are pressed in properly the controller Connection error Check that all connectors are pressed in properly Motor connector fault Press in the motor connector properly Appointment at your Decathlon regional Motor fault...

  • Page 17: Contents Of The Commercial Warranty For Your Electrical- Ly-Assisted Bike

    DECATHLON store loyalty card and register his/her purchase on it at the time of checkout, or complete the warranty certificate available online on the www.btwin.com site within one month of the purchase date. Du- ring this registration, the buyer must provide the following information: last name, first name, purchase date, e-mail address, and bicycle tracking number.
  • Page 18 DECLARATION OF CONFORMITY CE DECATHLON SA Company Name Adress 4 Bd de Mons BP 299 F-59665 VILLENEUVE D’ASCQ Declares to be authorised to establish the technical file Declares the product hereafter described : Commercial name : Bebike 900 / Elops 900 Model code : 8300083 Type : Electrically Power Assisted Cycle Brand : B’twin...
  • Page 20 DECATHLON - 4 Boulevard de Mons - BP 299 59650 Villeneuve d’Ascq cedex - France...
