DENT Instruments ELITEpro XC Quick Start Manual page 7

Specification
LED Indicators
USB (Standard)
ETHERNET
(Standard)
BLUETOOTH®
WIRELESS
TECHNOLOGY
(Optional)
WiFi ADAPTER
(Optional)
Line Power Supply
Power In
(optional)
Operating
Temperature
Humidity
Enclosure
Weight
Dimensions
Tri-colors (red, green, and blue): 1 LED to indicate communication, 4
LEDs for correct phasing (green when voltage and current on the same
phase; red when incorrectly wired, blue for wireless, Bluetooth wireless
technology, and Ethernet).
Communication
USB standard (Type B). 1.8 M (6 FT) A-to-B USB Cable (included)
Standard RJ-45 Connector supports 10/100 MB Ethernet over Cat 5 or
better. Configure for DHCP or Static IP address.
Internal antenna: typical conditions <10ft up to 100ft range. Requires
Bluetooth wireless technology adapter on Window PC. Adapter must
support the Serial Port Profile (SPP).
Internal WiFi adapter with two separate configurations:
Internal antenna: typical conditions <75ft up to 300ft
External 5 dbi antenna: typical conditions <150ft up to 300ft
From L1 Phase to L2 Phase. 80-600V (AC or DC) CAT III DC/50/60Hz, 125
mA, 5 W, or 10 VA max.
Non-user replaceable .5 Amp internal fuse protection.
6-10 VDC maximum, 500 mA minimum
Mechanical
-7 to + 60°C (20 to 140°F)
5% to 95% non-condensing
ABS plastic, 94-V0 flammability rating
340 g (12 ounces, excluding sensors and leads)
69 x 58 x 203 mm (2.7" x 2.2" x 8.0")
Description
Power
7
